Figure 1. MachXO2 Breakout Board, Top Side
MachXO2
PLD (U3)
Two 2x20
Header Landings
(J2, J4)
FTDI
USB to UART/FIFO
IC (U1)

Storage and Handling

Static electricity can shorten the lifespan of electronic components. Please observe these tips to prevent damage
that could occur from electro-static discharge:
• Use anti-static precautions such as operating on an anti-static mat and wearing an anti-static wrist-band.
• Store the evaluation board in the packaging provided.
• Touch a metal USB housing to equalize voltage potential between you and the board.

Software Requirements

You should install the following software before you begin developing new designs for the Breakout board:
®
• Lattice Diamond
design software
• FTDI Chip USB hardware drivers (installed as an option within the Diamond installation program)

MachXO2 Device

This board currently features the MachXO2-7000HE FPGA which offers embedded Flash technology for instant-
on, non-volatile operation in a single chip. Numerous system functions are included, such as two PLLs and 256
Kbits of embedded RAM plus hardened implementations of I
ble, high performance I/Os support numerous single-ended and differential standards including LVDS, and also
source synchronous interfaces to DDR/DDR2/LPDDR DRAM memory. The 144-pin TQFP package provides up to
4x15 60-Hole
LED Array (J4)
Prototype Array (J6)
JTAG Header
USB Mini-B
Landing (J1)
Socket (J7)
Evaluation Kit User's Guide
Power/GND
Power LED
Test Points
(PWR_ON)
(TP1, TP2, TP3)
2
C, SPI, timer/counter, and user Flash memory. Flexi-
3
MachXO2 Breakout Board
Two 2x20
Header Landings
(J3, J5)
