Web Browser - Vislink UltraDecoder Operator's Manual

You can control equipment using your preferred web browser via your network through
the ETHERNET CONTROL connector on the rear panel.
Whilst every effort is made to ensure that the interface works with all web browsers, we
cannot guarantee that it will be fully compatible with old versions or exceedingly new ones.
NOTE: We recommend using either IE (minimum version 7) or Firefox (minimum version
2.0.0.11).
When the interface is first accessed from your preferred browser, features required by the
interface are checked and their status displayed.
Normally, connection to the web interface would be achieved over a network, however it is
possible to directly connect a PC to the unit. If this is required and the PC Ethernet port is
not an autosensing type, use a crossover Ethernet cable.
Issue: 4
Ref: ULTD-ASUM-7001
Figure 9-1
ID
Status summary of unit. Top right icons for
1.
favourites, help and Home page.
Drop-down list of selectable items. Choose desired
2.
value, then press the Set button to apply.
Edit box. Type in the desired value, then press the
3.
Set button, or select the Enter button to apply.
Favourites selection. Click on this button to
4. illuminate it, to make it accessible from the
favourites button at the top right of the screen.
Table 9-1 Web Browser Overview Functions
Web Browser Overview
Function
UltraDecoder Operators Manual
Remote Control
Copyright © 2016 Vislink plc
32
