Parameters that can set the relay can be controlled via the web interface on the Alarm
Mask page, found under the Unit settings.
Pin Signal
1
2
3
4
5
6
7 GND
8
9
10
11
12
13
14

Status Relay

15 Status Relay
This USB connector is used for upgrading the internal decoder.
The ETH. 1 connector is used for incoming video into the decoder section.
ETH. 1 must be connected to the rear panel IP Video port either by the supplied short
Ethernet cable (if only ASI input mode is required) or via a network switch, if IP Input mode
is required.
The ETH.2 connector is used by the control subsystem for configuring the decoder.
ETH. 2 should be connected directly to the rear panel ETHERNET CONTROL port by the
supplied short Ethernet cable or, if remote control of the UltraDecoder is required, then
the connection must be made via a network switch.
This 75Ω BNC is used to provide an ASI output, which can be derived from the ASI In signal
or ASI over IP.
These HD BNCs output the following via industry standard 3G SDI interfaces:

1080P

1080i

720P

SD
Issue: 4
Ref: ULTD-ASUM-7001
Description
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
Relay contact opens on fault
Relay contact opens on fault
Table 6-1
-
-
-
-
-
-
-
-
-
-
-
-
-
Internal link to swap NC/NO
Internal link to swap NC/NO
Data Out Pinouts
