X-Terminator

Main Menu Options

1. Built-in Shows

01) Press the MODE button until the display shows
02) Press the ENTER button to enter the menu.
03) Press the UP and DOWN buttons to run one of the built-in shows:
04) Once your preferred show has been chosen, press the ENTER button to proceed to
speed settings.
05) Press the UP and DOWN buttons to adjust the speed of your preferred built-in show:

2. Sound-controlled Effect

This effect makes the unit respond to the beats of background music, being intercepted by the built-in
microphone.
01) Press the MODE button until the display shows
02) Press the ENTER button to enter the menu.
03) Press the UP and DOWN buttons to run one of the sound-controlled shows:
04) Turn the control (11) on the rear panel to the left or right to, respectively, decrease or increase
sensitivity of the device to background music.

3. Master/Slave Mode

01) Press the MODE button until the display shows
02) Press the ENTER button.
03) The laser is now operating in Slave mode and it will react the same as the master device.

4. DMX Mode

With this menu you can set the desired DMX address.
01) Press the MODE button until the display shows
02) Press the ENTER button again, the display will show
03) Press the ENTER button to enter the DMX Mode menu.
04) Press UP and DOWN buttons to choose one of the two available DMX modes:
2 channels
11 channels
05) If the display shows
06) Press the UP and DOWN buttons to select the DMX address between
07) If the display shows
08) Press the UP and DOWN buttons to select the DMX address between
Ordercode: 43157
Built-in programs
Sound-controlled
Master/Slave
DMX-512
System Settings
. The higher the value the faster the speed.
will appear on the display.
, press the ENTER button to enter the menu.
, press the ENTER button to enter the menu.
.
.
.
.
.
18
.
.
.
.
