Description of the device

Features

The X-Terminator is a laser effect with high output and great effects.
• When using multiple units together, you can make a dazzling and cost effective beam show
• Power Input: AC 100-240V, 60/50Hz
• Power Consumption: 40 Watt
• Beam Diameter <5mm at aperture
• Laser Class: 3B
• Strobe: 0-30Hz
• Laser Safety: EN/IEC 60825-1 Ed 2, 2007-03
• LED Color: Red, Green, Blue + White and Amber
• Laser Color: Red, Green
• Light source: 12 x 0,5W LED
• Laser Power: 130mW (100mW 650nm Red, 30mW 532nm Green)
• Control Modes: DMX-512, Built-in Programs, Master/Slave, Sound-controlled, IR remote controlled
• Divergence (each beam) <2 mrad; Divergence (total light) <160 degrees
• 3-pin DMX In and 3-pin DMX Out
• Clear red LED display for all settings
• Compact strong metal housing
• Sound-controlled via built-in microphone
• 2 and 11 DMX channel modes
• Safety Features: Key switch, Interlock
• Fuse: 1,6AL/250V
• Dimensions: 335 x 215 x 197 mm (LxWxH)
• Weight: 2,5 kg

Frontside

01) LED lens A
02) Remote control LED indicator
03) Laser lens
04) LED lens B
05) Cooling fan
06) Mounting bracket with inclined screw
Ordercode: 43157
9
Fig. 01
