Summary of Contents for SHOWTEC FX Blaster XL V1
- Page 1 MANUAL ENGLISH FX Blaster XL Ordercode: 61031 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
FX Blaster XL Table of contents Warning ....................................2 Unpacking Instructions ..............................2 Safety Instructions ................................. 3 Use ................................... 5 Indoor Use..................................5 Noise Level ..................................5 Operating Determinations ............................5 Rigging .................................... 6 Return Procedure ................................7 Claims ....................................7 Description of the device .............................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec FX Blaster XL in flight case ● Woofer ●... -
Page 4: Safety Instructions
FX Blaster XL Safety Instructions Every person involved with the installation, operation and maintenance of this device has to: ● be authorized ● follow the instructions of this manual ● We also insist that all new users (operators, installers, maintenance workers and cleaners) receive a training course during which they become thoroughly familiarized with this user manual. - Page 5 ● If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 6: Co 2 Use
Always use approved CO₂ cylinders, hoses and connections. Always consult your CO₂ supplier for regulations and instructions on safe installation and use. Showtec is not liable for unsafe situations, accidents and damages that are the result of incorrect working with CO₂ gas and CO₂ cylinders. -
Page 7: Rigging
Showtec is not liable for any consequential loss in the event of an FX Blaster XL breakdown. This user manual has been drawn up with the utmost care. Showtec cannot be held responsible for any mistakes made in this publication or for any consequences thereof. -
Page 8: Return Procedure
FX Blaster XL Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.com and request an RMA prior to shipping the... -
Page 9: Description Of The Device
For big concerts, stadiums and festivals you need special FX equipment that performs in a big way. The Showtec FX Blaster is the designated tool for the job. With an awesome combined output of 25 m with CO₂ and confetti, a capacity of 15 kg of confetti per minute or even 20 kg per 90 seconds, the FX Blaster is a magnificent eye-catcher that cannot be overlooked. -
Page 10: Optional Accessories
FX Blaster XL Optional accessories 61013 - CO 3/8 Q-Lock Hose 2,5 m 61014 - CO 3/8 Q-Lock Hose 5 m 61015 - CO 3/8 Q-Lock Hose 10 m 61016 - CO 3/8 Q-Lock Hose 15 m 61020 - CO₂ Bottle to 3/8 Q-Lock adapter 61021 –... -
Page 11: Installation
FX Blaster XL Please check the following table. Confetti types and related loads and output Type of confetti Max. load per blast Output distance Metallic confetti 20 kg 25 m Paper confetti 10 kg 25 m Snow or Powder confetti 5 kg 25 m Installation... -
Page 12: Co 2 Bottle Installation
FX Blaster XL Precautions for operation Using a damaged or an improperly installed machine can lead to death, serious injury or property damage. Always inspect the machine thoroughly before operation. Missing or obscured safety symbols on the machine can cause unawareness, which in turn can lead to death, serious injury or property damage. -
Page 13: Set Up And Operation
Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. The Showtec FX Blaster XL is designed to blow confetti with the help of CO gas. - Page 14 FX Blaster XL 03) Take all parts out of the case: A. Woofer B. 2x Woofer safety split pin C. 2x Woofer pin D. CO₂ bottle-to-hose connector E. 3/8 Manual CO₂ valve F. CO₂ high pressure hose 3/8 Male – Female (3 m) G.
- Page 15 FX Blaster XL 05) Secure the pin with a safety split pin. 06) Set the angle of the woofer by aligning the back pinhole with one of the four predefined holes in the case. Ordercode: 61031...
- Page 16 FX Blaster XL 07) Insert the second pin through the back pinholes to secure the position of the woofer. 08) Secure the pin with a safety split pin. Ordercode: 61031...
- Page 17 FX Blaster XL 09) Position the machine and set the brakes on all 4 wheels. 10) Make sure you have taken all the necessary safety precautions, see pages 10–11. 11) Connect the CO valve to the CO input of the woofer and tighten the nut with the adjustable wrench.
- Page 18 FX Blaster XL 12) Connect the CO hose to the CO valve. 13) Make sure that the CO valve is in the CLOSED position. Ordercode: 61031...
- Page 19 FX Blaster XL 14) Connect the CO₂ bottle-to-hose connector to a CO cylinder. 15) Connect the CO hose to the CO₂ bottle-to-hose connector on the CO cylinder. Turning it by hand should suffice! Use the wrench only if the coupling continues to leak. 16) Open the CO cylinder and check for leaks.
-
Page 20: Fill With Confetti And Blast
FX Blaster XL Fill with confetti and blast 01) Make sure that the prescribed safety zone of 3 m is free from people and objects. The environmental noise level as measured at the ear is 97 dB(A). This level of noise is only reached during the short instances that the CO₂... - Page 21 FX Blaster XL 04) Enjoy the show! 05) When you are finished blasting confetti, move the manual CO₂ valve back to the CLOSED position. Ordercode: 61031...
-
Page 22: Replace A Co Cylinder
FX Blaster XL Replace a CO cylinder 01) Make sure that the CO valve is in the CLOSED position. 02) Close the connected CO cylinder. 03) Move the manual CO valve to the OPEN position to release the pressure from the system. Ordercode: 61031... - Page 23 FX Blaster XL 04) Disconnect the CO hose from the CO bottle-to-hose connector on the CO cylinder. 05) Remove the CO bottle-to-hose connector from the cylinder. 06) Connect the CO bottle-to-hose connector to a new CO cylinder. Ordercode: 61031...
- Page 24 FX Blaster XL 07) Connect the CO hose to the CO bottle-to-hose connector on the new CO cylinder. 08) Move the manual CO valve back to the CLOSED position. 09) Open the CO cylinder. Ordercode: 61031...
-
Page 25: Disassembling + Storing The Fx Blaster Xl
FX Blaster XL Disassembling + Storing the FX Blaster XL 06) Close the connected CO cylinder. 07) Move the manual CO valve to the OPEN position, to release the pressure from the system. 08) Remove the CO hose. Ordercode: 61031... - Page 26 FX Blaster XL 09) Disconnect the CO hose from the CO bottle-to-hose connector on the CO cylinder. 10) Remove the CO bottle-to-hose connector from the cylinder. Note: Fasteners in the vicinity of the output pipe can become frozen due to the use of CO .
- Page 27 FX Blaster XL 11) Unscrew the nut and remove the CO₂ valve. 12) Remove the 2 safety split pins and then remove the 2 pins while holding the woofer and remove the woofer. 13) Remove the remaining confetti from the hopper. Ordercode: 61031...
- Page 28 FX Blaster XL 14) Store all parts in the case. 15) Place and lock the top cover. Ordercode: 61031...
-
Page 29: Declaration Of Conformity
FX Blaster XL Declaration of Conformity Ordercode: 61031... -
Page 30: Maintenance
FX Blaster XL Maintenance The Showtec FX Blaster XL requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s performance will be significantly reduced. Disconnect the mains power supply and then wipe the cover with a damp cloth. Do not use alcohol or solvents. Do not immerse in liquid. -
Page 31: Product Specification
FX Blaster XL Product Specification Model: Showtec FX Blaster XL Dimensions: 660 x 380 x 1350 mm (LxWxH) Weight: 56 kg Input: Liquid CO Output: gas + confetti Specs Power: Liquid or gaseous CO Propellant connector: 0,5 L/sec. Housing: Black Metal Consumption: Confetti Max. -
Page 32: Dimensions
FX Blaster XL Dimensions Ordercode: 61031... -
Page 33: Notes
FX Blaster XL Notes Ordercode: 61031... - Page 34 FX Blaster XL Ordercode: 61031...
- Page 35 FX Blaster XL Ordercode: 61031...
- Page 36 ©2019 Showtec...
