X-Terminator

IR Remote Control

Button
Auto Mode
Sound-controlled Mode
LED Mode
Laser Mode
Flash Mode
Auto / Sound switch
Color changing
Numeric keys
Attention:
Any settings saved with the remote control will be stored until the system has been rebooted.

Installation

Remove all packing materials from the X-Terminator. Check if all foam and plastic padding is removed.
Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.

Set Up and Operation

Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply. The device can be music-controlled by its built-in
microphone.
Ordercode: 43157
Function Description
On / Off Power on / off
Set the auto mode
Set the sound-controlled mode
Set the LED mode
Set the laser mode
Set the flash mode
Switch between auto / sound modes
Pause Play/pause the show
Select the LED color
Program speed adjustment (1-9)
