Summary of Contents for National Flooring Equipment 5280
- Page 1 5280 SELF-PROPELLED SCRAPER INSTRUCTION MANUAL Read Manual Before Operating Machine 401871 Rev C...
-
Page 3: Table Of Contents
Table of Contents Table of Contents ........................................3 ....................................4 Components and Assembly ....................................8 Transport ........................................8 Preparing Machine for Job.................................... 8 Operation ..........................................10 Operating Controls...................................... 10 Application Setup ......................................10 Blade Sharpening ....................................10 Troubleshooting Guide ......................................12 Warranty .......................................... - Page 4 (full load) (119.3 kg) (43.2 cm) (68.6 cm) (99.1 cm) Machine Variants Region Serial Number Input Power Body Panels 5280-10XXXX 120V / 60 Hz Silver Vein Domestic 5280-23XXXX 120V / 60 Hz Silver Vein 5280-11XXXX 230V / 50 Hz Silver Vein...
- Page 5 Read the manual carefully to learn equipment applications and limitations, as well as potential hazards associated with this type of equipment. Keep manual near machine at all times. If your manual is lost or damaged, contact National Flooring Equipment (NFE) for a replacement. Personal Maintenance &...
- Page 6 Safety Safety WALK-BEHIND SCRAPER SAFETY GUIDELINES Before use, anyone operating this equipment must read and understand these safety instructions. Scraping Beware of hidden obtrusions. use on largely uneven surfaces. Observe location of electrical supplies and extension cords. Do not allow cutting heads to come into contact with any electrical supply or extension cord.
- Page 7 Safety HYDRAULIC SAFETY Maintaining a Safe Work Environment Establishing a safe work environment in and around your hydraulic equipment is extremely important. The easiest and most effective way to avoid problems is to make sure associates understand their equipment, know how to operate the machines safely, and recognize the dangers if handled carelessly.
-
Page 8: Components And Assembly
Components and Assembly TRANSPORT easier. WARNING: REMOVE TRANSPORT WHEEL ASSEMBLY WHEN GOING UP OR DOWN A LOADING RAMP OR INCLINE. FAILURE TO DO SO COULD CAUSE DAMAGE TO MACHINE OR PROPERTY, OR CAUSE SEIOUS INJURY. FIG. 1 Attaching/Removing Transport Wheels Remove the two outside blade cover bolts (Figure 1). - Page 9 Components and Assembly Wider is not always better or faster. • Normally, bevel on the blade is up for concrete (Figure 3); bevel down for wood (Figure 3.1). • Dull blades greatly affect the performance of the machine and reduce cutting ability. Re-sharpen or replace blades as needed.
-
Page 10: Operation
Operation OPERATING CONTROLS Start-Up Procedure: Machine must be turned off before plugging machine into power source. Plug machine into outlet. Turn speed control to slowest position. FRONT OF BLADE For domestic machines: Flip ON/OFF switch to the “ON” position. For international machines: Push the green start button. BACK BEVEL Compress handle to move forward. - Page 11 Operation • Pass grinder along blade edge starting on one end and continuing in one direc- tion, being careful to hold grinder at proper angle of blade. Grind until sharp. • • Blades are sharp. Use extreme caution. • Have plenty of sharp blades on each job so on-the-job blade sharpening is elimi- nated.
-
Page 12: Troubleshooting Guide
Troubleshooting Guide Problem Cause Solution No forward movement. Damaged belt. Remove front cover plate and inspect belt. Damaged speed control valve. Inspect speed control valve. Turn counter-clockwise to open valve. Push reset button located on the electric box on the motor. -
Page 13: Warranty
Warranty National Flooring Equipment Inc. (referred to as “the Company”) warrants that each new unit manufactured by The Company, to be free from defects in material and workmanship in normal use and service for a period of twelve (12) months from date of shipment from the Company. For furnished and installed on the product by the Company but manufactured by others, including but not limited to: engines, motors, electrical com- ponents, transmissions etc., shall carry the accessory manufacturers own warranty. - Page 14 9250 Xylon Avenue N • Minneapolis, MN 55445 • U.S.A. Toll-free 800-245-0267 • Phone 763-315-5300 • Fax 800-648-7124 • Fax 763-535-8255 Web Site: www.nationalequipment.com • E-Mail: info@nationalequipment.com...
