MAKERBOT REPLICATOR 2 DIAGRAM

[1] GANTRY SYSTEM

[2] LCD PANEL

[3] KEY PAD

[4] THREADED Z-AXIS ROD

[5] BUILD PLATE

[6] BUILD PLATFORM

[7] FILAMENT GUIDE TUBE

[8] EXTRUDER CABLE

[9] EXTRUDER

[10] FILAMENT SPOOL

[11] SPOOL HOLDER

B SETTING UP YOUR MAKERBOT REPLICATOR 2 DESKTOP 3D PRINTER

MB2020_REP2_UserManual_V4.indd 11
