- Page 1 Vertrieb von CAMBOARD Electronics K R A ME R E LE CT R O N IC S L T D . USER MANUAL MODEL: RC-54DL KNET™ Auxiliary Control Panel P/N: 2900-300130 Rev 1 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
-
Page 2: Table Of Contents
Contents Introduction Getting Started Achieving the Best Performance Overview The RC-54DL KNET™ Auxiliary Control Panel Front Side The RC-54DL KNET™ Auxiliary Control Panel Rear Side Connecting the RC-54DL KNET™ Auxiliary Control Panel Grounding the RC-54DL Operating the RC-54DL Front Panel Button Caps and Labels... -
Page 3: Introduction
Vertrieb von CAMBOARD Electronics Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have redesigned and upgraded most of our... -
Page 4: Getting Started
Do not secure the cables in tight bundles or roll the slack into tight coils • Avoid interference from neighboring electrical appliances that may adversely influence signal quality • Position your Kramer RC-54DL away from moisture, excessive sunlight and dust Caution: No operator serviceable parts inside the unit Warning:... -
Page 5: Overview
Vertrieb von CAMBOARD Electronics Overview The RC-54DL is a 3 gang US, auxiliary room controller that acts as an all-in-one extended remote control panel for remotely controlling room controllers (for example, the Kramer RC-74DL) in classrooms, boardrooms or auditoriums. -
Page 6: The Rc-54Dl Knet™ Auxiliary Control Panel Front Side
Vertrieb von CAMBOARD Electronics The RC-54DL KNET™ Auxiliary Control Panel Front Side This section defines the RC-54DL: Figure 1: RC-54DL Front Panel Feature Function 6 Configurable Button Function is programmed by the K-Config Configuration Switches software LCD Label Displays up to 8 characters at once (set by the K-Config... -
Page 7: The Rc-54Dl Knet™ Auxiliary Control Panel Rear Side
Vertrieb von CAMBOARD Electronics T he RC-54DL KNET™ Auxiliary Control Panel Rear Side 1 0 B Figure 2: RC-54DL Rear Panel Feature Function RESET TO DEFAULT Disconnect the power and then connect it while pressing Button the RESET TO DEFAULT button (using a small screwdriver). -
Page 8: Connecting The Rc-54Dl Knet™ Auxiliary Control Panel
3, do the following: 1. Connect the K-NET ports to any RC devices with K-NET (for example, the RC-63DL and SL-12). 2. Connect the 12V DC power adapter to the RC-54DL power socket and to the mains electricity (not shown in Figure Alternatively, the RC-54DL can receive power over the K-NET port via the connected master room controller. -
Page 9: Grounding The Rc-54Dl
3. Insert the M3x6 screw (with the two toothed lock washers and ring tongue terminal) into the grounding screw hole and tighten the screw. RC-54DL – Grounding the RC-54DL www.camboard.de Tel. 07131 911201 ce-info@camboard.de... -
Page 10: Operating The Rc-54Dl
For instructions on using the software, see the K-Config Software Guide available from our Web site. Once configured, use the front panel buttons as a remote controller for the connected master room controllers. Figure 5: RC-54DL to RC-74DL Pinout Connection RC-54DL - Operating the RC-54DL www.camboard.de Tel. -
Page 11: Front Panel Button Caps And Labels
Vertrieb von CAMBOARD Electronics Front Panel Button Caps and Labels The RC-54DL is supplied with a button label sheet and 12 clear, button caps to house the labels. Figure 6 illustrates a sample button label sheet. RC-54DL – Front Panel Button Caps and Labels www.camboard.de... - Page 12 Vertrieb von CAMBOARD Electronics RC-54DL - Front Panel Button Caps and Labels www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
-
Page 13: Figure 6: Sample Button Label Sheet
Vertrieb von CAMBOARD Electronics Figure 6: Sample Button Label Sheet RC-54DL – Front Panel Button Caps and Labels www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... -
Page 14: Installing The Front Panel Button Caps, Labels
Figure 9 4. Retaining the orientation, place the button cap over the buttons of the RC-54DL. Figure 9: Placing the Button Cap RC-54DL - Front Panel Button Caps and Labels www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... - Page 15 6. Remove the protective foils from both sides of the Perspex (acrylic glass) windows. 7. Place the faceplate on the RC-54DL so that the four screw mounting holes are aligned. 8. Insert the four mounting screws and tighten with a screwdriver.
-
Page 16: Technical Specifications
16.2cm x 2.6cm x 11.4 (6.4" x 1.0” x 4.5") W, D, H WEIGHT: 0.6kg (1.4lbs) approx. ACCESSORIES: Power supply Specifications are subject to change without notice Go to our Web site at http://www.kramerelectronics.com to access the list of resolutions RC-54DL - Technical Specifications www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... - Page 17 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
- Page 18 Vertrieb von CAMBOARD Electronics For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com...
