Commax DRC-41UN User Manual

Door camera

Hide thumbs Also See for DRC-41UN:

Download this manual See also: User Manual

User Manual

Door camera DRC-41UN

• Thank you for purchasing COMMAX products.

• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

• The company is not responsible for any safety accidents caused by abnormal operation of the product.

Do you have a question about the DRC-41UN and is the answer not in the manual?

Page 1: User Manual
User Manual Door camera DRC-41UN • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. • The company is not responsible for any safety accidents caused by abnormal operation of the product.
Page 2 1. Overview 2. Installation & Wiring ① Line up the holes of wall and ▶ flush box and fix it on the wall. Installation ② Do the monitor wiring cosidering the polarity according to the image Camera Lens (Wiring diagram) LED &...
Page 3 3. Package 4. Specification Model DRC-41UN Power source 12V (from Monitor) Wiring 4wires(Polariry)C Camera Module C-MOS(COLOR) Communication 1/3 Inch Duplex Door Camera Flush box Frequency PAL STANDARD Min. Lux. 0.1Lux(300mm from camera) Light (Operation in Dark) Camera Angle Horizontal 82°, Vertical 66.5°...
