User Manual
User Manual DRC-40DK/41DK
• Thank you for purchasing COMMAX products.
• Thank you for purchasing COMMAX products.
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
Advertisement
Related Manuals for Commax DRC-40DK
Summary of Contents for Commax DRC-40DK
- Page 1 User Manual User Manual DRC-40DK/41DK • Thank you for purchasing COMMAX products. • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.
-
Page 2: Table Of Contents
Contents Safety Warning & Caution ······································· 2 1. Overview ························································ 4 2. How to use ····················································· 4 3. Wiring Diagram ·············································· 10 4. Installation ···················································· 11 5. Package ······················································· 11 6. Specification ················································· 12... -
Page 3: Safety Warning & Caution
Safety Warning & Caution Please follow the things described below in order to prevent any danger or property damage. Prohibition. Warning It may cause a serious damage or No disassembly injury if violated. No touch Must follow strictly. Shows plugging out the power cord Caution It may cause a minor damage or without an exception... - Page 4 Warning Please don’ t disassemble, If an abnormal sound, burning Please don’t insert any Please use only the designated repair or rebuild this product smell or smoke is coming out metallic or burnable materials batteries for the products of of the product, please plug out arbitrarily (please contact the into the ventilation hole.
-
Page 5: Overview
1. Overview contents contents Camera Enter button Speaker Microphone White LED & Illuminance sensor Call button Keypad button RF Card Tag Back/Cancel button Camera angle adjustment Connecting port/ WIRE for door realese Anti-theft switch 2. How to use * Default behavior - This product uses DC 12V / 1A adapter (RF-1A recommended, sold separately). - Page 6 * Button description Image Description Back, Cancel ⑤ (C : Cancel) Use this button to cancel the function. OK Button ⑥ (E : Enter) Use this button for setting and execution. * Anti-theft alarm function ⑫ - To prevent the device from being stolen, the alarm sounds when removed from the wall. However, the alarm sounds only when power is supplied to the unit.
- Page 7 2-2-1. Password setting 1) Password registration / change ① Press program number (0) and press OK button (E) ② Enter the existing password (Initial: 1, 2, 3, 4) and press the OK button (E) ③ If the password change mode is successfully entered, the KEY LED will blink. ④...
- Page 8 3) Delete individual RF cards ① Press program number (4) and press OK button (E) ② Enter the password and press the OK button (E). ③ When individual deletion mode is successfully entered, the KEY LED will blink. ④ Tag the card to be deleted to the RF receiver. If you tag another card continuously, you can delete multiple cards at once.
- Page 9 5) Door opening with password - Door open by Password ① After entering the password, press the door number you want to open and then press OK button (E). ex) When opening door # 1: 2580 -> 1 -> OK button (E) - Door open by RF card ①...
- Page 10 7) Beep(Touch and so on) Volume adjustment ① Press program number (7) and press OK button (E) ② Enter the password and press the OK button (E). ③ When the beep volume control mode is successfully entered, the KEY LED will blink.
-
Page 11: Wiring Diagram
9) Touch LED setting ① Press program number (9) and press OK button (E) ② Enter the password and press the OK button (E). ③ If touch LED setting mode is successfully entered, the KEY LED will blink. ④ LED ON only when the key touched: Input 0 LED ON every time with power supplied: Input 1 ⑤... -
Page 12: Installation
4. Installation 5. Package Item Description CONN. 4Px300 4 wire connector CONN. 2Px300 2 wire connector Bracket Bracket for installation Screw GH1T 4x18 Bracket screw Screw PHM 3x8 Bracket + Monitor User Manual English version manual... -
Page 13: Specification
RF Module 13.56MHz Operation temp. -10℃(tested up to -40℃) ~ +50℃ Dimension (mm) DRC-40DK : 127(W)x193(H)x54(D), DRC-41DK : 127(W)x193(H)x63(D) 28 meters (Φ 0.5 UTP), It must be observed. Distance Resistance under 10 Ω per 100 meters on UTP Cat 5e. <Caution>... - Page 14 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com Web site : www.commax.com PM0743KM0010 Printed In Korea / 2016.04.104...
