1. Overview
Angle
Adjuster
Volume
Controller VR
Camera Lens
LED &
illumination Sensor
FHM 4X40
Speaker
(4EA)
Name card
Call button
Microphone
Door
Release cable
Monitor
Connecting
Terminal
2. Installation & Wiring
▶
Installation
▶
Wiring
① Line up the holes of wall and
flush box and fix it on the wall.
② Do the monitor wiring cosidering
the polarity according to the image
(Wiring diagram)
③ Fit the product from the above and
press it against the bracket.
Then, check the monitor screen,
if it shows the place that you would
like to see.
④ Fix it from the bottom with the screw
Position of camera
▶
66.5°
