- Page 1 .in.ua www.commax.in.ua Entrance Camera Model No. DRC-4BG/4CG Use And Care Guide...
- Page 2 Table of Contents 1. G reeting !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! 2 2. O verview !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! 3 3. Wiring and Installation !!!!!!!!!!!!!!!!!!!!!!!!!!!! 4 4. Specification !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!" 1. Greetings * Thank you for purchasing a C O MMAX product. * Please read this manual before use and properly follow its instructions. !! "...
- Page 3 2. Overview N o. N ame contents Front Panel Mounting Holes Speaker Transmits sounds from the household. C amera Lens Protect it from foreign substances. LED Lamp Turns on at night for better viewing. For use when communicating with the household. Page Button Used to page the household.
- Page 4 3. Wiring and Installation 1. C ut out the mounting template included in the manual and use it to drill mounting holes (# 6.5) on the wall. Insert C oncrete anchors in the holes. 2. W ire the household monitor cable as shown below, with matched polarity. [FIG -2] (#1:RED/VO IC E, #2:BLUE/G N D, #3:YELLO W /DC 12V, #4:BLAC K/VIDEO ) 3.
- Page 5 [MO UN TIN G TEMPLATE]...
- Page 6 !! % !
- Page 7 4 . Specification M o d e l D R C - 4 B G / 4 C G S p e c i f i c a t i o n Resolution 270,000 pixel C C D Rated Voltage DC 12V (supplied from the monitor) W iring Method (household) 4-wire polarity...
- Page 8 C ommax User Manual 05-08-01 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, G yeonggi-do, Korea Int’l Business Dept : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 W eb site : www. commax. com Printed In Korea...
