FastTrak TX2200, TX2300 User Manual
Install the FastTrak Card
The FastTrak TX2200 or TX2300 Serial ATA RAID card fits into any available
PCI slot on your PC's motherboard (below):
•
32-bit PCI slot (must be PCI 2.2 or 2.3 compliant)
•
The 32-bit portion of a 64-bit PCI or PCI-X slot
FastTrak Serial
ATA RAID card
Motherboard
1.
Remove the cover of your system.
2.
Install the FastTrak Serial ATA RAID card into the open PCI slot.
The FastTrak TX Series RAID Controller card is a PCI Plug-n-Play
(PnP) device. No changes are necessary in the motherboard
CMOS/BIOS Setup for resources or drive types in most
applications.
Attaching screw
Bracket
Note
System frame
8
PCI slots
