A2SDi-HLN4F Series User's Manual

Motherboard Features

CPU
•
Intel® Atom SoC C3000 Series (FCBGA1310) Processor
Memory
•
Up to 256GB RDIMM or 64GB UDIMM DDR4 ECC/Non ECC up to 2400MHz
(On select SKUs, 2400MHz modules can be used but will operate at a lower speed)
DIMM Size
•
4GB, 8GB, 16GB, 32GB, and 64GB
Expansion Slots
•
One (1) PCI Express 3.0 x4 Slot (combined number of SATA ports and PCIe lane on slot is up to eight on -2C/4C models)
•
One (1) M.2 PCI Express 3.0 x2 Slot (not available on the -2C model)
Network
•
Intel X553 Gigabit Ethernet Controller
BaseBoard Management Controller (BMC)
•
ASpeed AST 2400 Baseboard Controller (BMC) supports IPMI 2.0
•
One (1) Dedicated IPMI LAN port located on the rear IO back panel
Graphics
•
Graphics controller via ASpeed AST2400 BMC
I/O Devices
•
Serial (COM) Port
•
SATA 3.0 Ports
Peripheral Devices
•
Two (2) USB 2.0 ports on the rear I/O panel (USB0/1)
•
Two (2) USB 2.0 ports in one internal header (USB2/3)
•
One (1) USB 3.0 Type A port (USB4)
Note: The table above is continued on the next page.
•
One (1) COM header
•
Twelve (12) SATA 3.0 ports (4 via ports, 8 via miniSAS HD) for -8C/8C+/12C/16C.
•
Up to Eight (8) SATA 3.0 ports (4 via ports, 4 via miniSAS HD) for -2C/4C
(combined number of SATA ports and PCIe lane on the expansion slot is up to
eight on -2C/4C models)
16
