A2SDi-HLN4F Series User's Manual

Quick Reference Table

Jumper Description
JBR1 BIOS Recovery
JBT1 CMOS Clear
JI C1/JI C2 SMB to PCI-E Slots Enable/Disable
2 2
JPG1 VGA Enable/Disable
JPL1 LAN Enable/Disable
JPME2 ME Manufacturing Mode
JWD1 Watch Dog
LED Description
LED1 Onboard Power LED
LEDM1 BMC Heartbeat LED
UIDLED1 UID LED
Connector
BT1
COM1
FAN1 ~ FAN3, FANA
IPMI LAN
I-SATA0 ~ I-SATA3
JD1
JF1
JGP1
JL1
JMD1
JPH1
JPI C1
2
JPV1
JPW1
JRT3
JRT4
JSAS1
JSAS2
JSD1
JSMB1
JTGLED1
JTPM1
LAN1 ~ LAN4
Note: Table is continued on the next page.
Description
Onboard Battery
COM Header
System/CPU Fan Headers (FAN1: CPU Fan)
Dedicated IPMI LAN Port
Intel SATA 3.0 Ports (I-SATA0 supports SuperDOM)
Speaker Header
Front Control Panel Header
General Purpose I/O Header
Chassis Intrusion Header
M.2 PCI-E 3.0 x2 / I-SATA Slot (Not available on -2C model)
4-pin Power Connector for HDD use (To provide power from the motherboard to onboard
HDD devices)
Power Supply SMBbus I C Header
2
4-pin DC Power Connector (To provide alternative power for special enclosure when the 24-
pin ATX power is not in use.)
24-pin ATX Power Connector
Thermal Diode 1 Header
Thermal Diode 2 Header
I-SATA Ports 4-7
I-SATA Ports 8-11 (Not available on -2C/-4C models)
SATA DOM Power Connector
SMBus Header
LAN3/LAN4 Front Activity LED
Trusted Platform Module/Port 80 Connector
Gigabit Ethernet (RJ45) Ports
14
Default Setting
Pins 1-2 (Normal)
Open (Normal)
Pins 2-3 (Disable)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Normal)
Pins 1-2 (Reset)
Status
Solid Green: Power On
Blinking Green: BMC Normal
Solid Blue: Unit Identified
