2.4 Memory Support and Installation

Note: Check the Supermicro website for recommended memory modules.
Important: Exercise extreme care when installing or removing DIMM modules to pre-
vent any possible damage.
Memory Support
The A2SDi-2C-HLN4F supports up to 128GB RDIMM or 32GB ECC/Non-ECC UDIMM DDR4
in two memory slots, two DIMM on single channel at up to 1866MT/s .
The A2SDi-4C-HLN4F support up to 256GB RDIMM or 64GB ECC/Non-ECC UDIMM DDR4
in four memory slots, two DIMM Per Channel (DPC) at up to 2133MT/s.
The A2SDi-8C/8C+/12C/16C-HLN4F support up to 256GB RDIMM or 64GB ECC/Non-ECC
UDIMM DDR4 in four memory slots, two DIMM Per Channel (DPC) at up to 2400MT/s.
Populating these DIMM slots with a pair of memory modules of the same type and size will
result in interleaved memory, which will improve memory performance.
Memory Population Guidelines
For optimal memory performance, follow the table below when populating memory. Populate
DIMM slots in the following order: DIMMA1, DIMMB1, then DIMMA2, DIMMB2
DIMMA1
4GB
4GB
8GB
8GB
16GB
16GB
32GB
32GB
64GB
64GB
DIMMs per
channel
1
2
Recommended Population (Balanced)
DIMMB1 DIMMA2 DIMMB2
4GB
4GB 4GB
8GB
8GB 8GB
16GB
16GB 16GB
32GB
32GB 32GB
64GB
64GB 64GB
Unbuffered DDR4 ECC/Non-ECC DIMM Memory
DIMMs per DIMM Type
channel
1 Unbuffered
DDR4 DIMM
2 Unbuffered
DDR4 DIMM
27
Total System Memory
8GB
4GB 16GB
16GB
8GB 32GB
32GB
16GB 64GB
64GB
32GB 128GB
128GB
64GB 256GB
POR Speed Memory Population
MT/s Sequence
1866, 2133, 2400 A1, A2 (2 DIMMs)
1866, 2133, 2400 A1, B1, A2, B2
(4 DIMMs)
