MAINTENANCE

•
Before opening the case, always disconnect test leads
from all energized circuits.
•
Never use the meter unless the back cover is in place and
fastened completely.
•
Do not use abrasives or solvents on the meter. To clean it
using a damp cloth and mild detergent only.
•
Qualified and trained service technicians should only
perform calibration and repair of the meter.
•
Do not attempt calibration or service unless trained and
another person capable of rendering first aid and
resuscitation is present.
GENERAL DESCRIPTION
The meter is a handheld 3 1/2 digital clamp meter for measuring
DC and AC voltage, AC current, Resistance, Diode and Continuity
Test with battery operated.
FRONT PANEL DESCRIPTION
Transformer jaws
Pick up the AC current flowing through the conductor.
Hold button
When this button is pushed, the display will keep the last
reading and "
pushing it again.
Rotary switch
This switch is used to select functions and desired
ranges.
" symbol will appear on the LCD until
-3-
