Summary of Contents for Mastech MS20006

  • Page 1: Table Of Contents

    MS2000G CONTENTS DIGITAL AC/DC CLAMP METER SAFETY INFORMATION .……………………………2 SAFETY SYMBOLS .…………………………………2 SAFETY PRECAUTIONS ……………………………3 MAINTENANCE .………………………………………4 GENERAL DESCRIPTION …..………………………4 FRONT PANEL DESCRIPTION …..…………………5 OPERATING INSTRUCTIONS ………………………8 SPECIFICATIONS …...……………………………11 MASTECH REPLACING THE BATTERY ...……………………12 ACCESSORIES ………………………………………13 HOLD...
  • Page 2: Safety Information

    SAFETY INFORMATION respond to unwanted signals that may be present within the measurement circuit. The digital clamp meter has been designed according Users should exercise care and take appropriate to IEC1010 – 1 and IEC1010 – 2 – 032 concerning precautions to avoid misleading safety requirements for electrical measuring instruments and hand –...
  • Page 3: Maintenance

    measuring DC and AC voltage, AC current, Resistance, dry clothing; rubber shoes, rubber mat, or any approved Frequency, Temperature (°C&°F), Diode and Continuity insulating material. Test with battery operated. ●You always are careful when working with voltages above 60V dc or 30V ac rms. Keep fingers behind the FRONT PANEL DESCRIPTION probe barriers while measuring.
  • Page 4 This is the positive input terminal for ohms. Connection is made to it using the red test lead. Temperature Measuring Socket Insert a “K” type thermocouple into the temperature measuring socket and contact the object to be MASTECH measured with the thermocouple probe. (10) Trigger HOLD Press the lever to open the transformer.
  • Page 5: Operating Instructions

    OPERATING INSTRUCTIONS 1.Connect the red test lead to “Ω” jack and black test DC VOLTAGE MEASUREMENT lead to the “COM” jack. (The polarity of red lead is 1.Connect the red test lead to the “VHz” jack and the positive “+”.) black lead to the “COM”...
  • Page 6: Specifications

    2.Inserts “K” type thermocouple into the temperature is positive “+”.). measuring socket on the front panel and contact the 2.Set the rotary switch at “ ” position. object to be measured with the thermocouple probe. 3.Connect the red test lead to the anode of the diode to 3.
  • Page 7 AC VOLTAGE “-”displayed for negative Polarity indication polarity Range  Resolution  Accuracy Overrange Indication Only figure “1” on the display 200V 0.1V ±1.0% of rdg ± 3 digit Jaw opening capability 55mm (Max conductor size) 750V 9V battery, NEDA 1604 or Power Input Impedance: 10MΩ...
  • Page 8: Replacing The Battery

    TEMPERATURE If “ ”appears on display, it indicates that the battery Range  Resolution  Test Range Accuracy should be replaced. Use the following procedure to replacing the battery: ±1.0% of rdg ± 3 °C 0°C to 400°C 1°C 1.Disconnect test leads from any live source, turn 0°C to 750°C ±2.0% of rdg ±...
