Summary of Contents for PR Lighting XPar 150
- Page 1 XPar 150 PR-8202 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
-
Page 2: Table Of Contents
INDEX SAFETY AND WARNINGS…………………………………………………………………………………………………… INSTUCTIONS ………………………………………………………………………………………………………………… ●CLEANING AND MAINTENANCE ………………………………………………………………………………………… ●TROUBLESHOOTING………………………………………………………………………………………………………… 3. APPEARANCE ………………………………………………………………………………………………………………… 4. INSTALLATION ……………………………………………………………………………………………………………… ●RIGGING ……………………………………………………………………………………………………………………… ●PLACE A UNIT ON A FLAT SURFACE……………………………………………………………………………………… ●INSTALLATION OF BARN DOOR…………………………………………………………………………………………… ●TRANSPORTATION…………………………………………………………………………………………………………… ●POWER CONNECTIONS …………………………………………………………………………………………………… ●DMX CONTROL CONNECTION …………………………………………………………………………………………… ●DMX TERMINATOR ………………………………………………………………………………………………………… 5. -
Page 3: Safety And Warnings
1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Warning Flames Goggles Manual shock Gloves Temperature ●... -
Page 4: Instuctions
●After running for 5minutes at constant temperature environment, the temperature of the housing of the projector is 45℃.After stable operation , its temperature is 50℃. ●While the lamp is stricken for the first time, there will be smoke and strange smell. It’s normal and does not mean the projector has some defects. -
Page 5: Appearance
3. APPEARANCE (The unit has two different settings. One is with wireless control function and the other version without it. After either version leaves the factory, they can’t be changed in between as you like) With wireless control function Without wireless control function Product’s External Functional Sketch：... -
Page 6: Installation
4. INSTALLATION on flat surface with antenna facing up Safety Cord run through safety cord hole Support hung with antenna facing down ●RIGGING Before moving the unit, lock the adjusting knob. Take 1 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp. -
Page 7: Transportation
If the frost panel is also selected , it must be used in combination of the barn door. Its Installation and Dismantlement is illustrated in the diagrams below: barn door frost panel screws ×4 The unit with a barn door is as follow: ●... -
Page 8: Dmx Control Connection
● DMX CONTROL CONNECTION: Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets. -
Page 9: Setup And Configuration
5. SETUP AND CONFIGURATION ● FRONT PANEL OPERATION Projector configuration can be set conveniently via push button and LCD display. Launch the projector and press button ENTER for more than 3 seconds to unlock the panel, the LCD will show the function menu of the projector, each main menu has its submenus and each submenu has a specific function. -
Page 10: Operation Menu
6. OPERATION MENU (Those contents within the black box are only for the version with wireless control function) level menu level menu level menu level menu Standard:001-506 DMX Address Extended:001-501 Standard 6 DMX Channel Mode Extended 11 （Default：STD6） XLR First DMX Mode XLR Only （Default：XLR First）... -
Page 11: Dmx Protocol
Note: In one DMX chain, only one unit can be made as the master. Before master works, unplug its XLR cable connected with the console. The parameters transmitted from the master include after several units are synchronized: DMX channel mode, display settings(display contrast excluded),operation mode(including user memory).During parameter transmission, set the unit transmitting data as master and others as slave 7. - Page 12 160-175 Preset memory 11 176-191 Preset memory 12 192-207 Preset memory 13 208-223 Preset memory 14 224-239 Preset memory 15 240-255 Preset memory 16 001-015 User Memory1 016-031 User Memory2 032-047 User Memory3 048-063 User Memory4 064-079 User Memory5 080-095 User Memory6 096-111 User Memory7...
-
Page 13: Technical Data
TECHNICAL DATA INPUT VOLTAGES: 100V~240V AC，50/60Hz RATED POWER :200W@220V LIGHT SOURCE SPECIFICATIONS: Single COB light source （RGBW） Power Consumption 150W Manufacturers Rated Lamp Life 50000hours COLORS : R/G/B/W linear color mixing with macros DIMMING: Linear Dimming from 0-100% STROBE: Electronic Strobe 0.5-33FP.S. BEAM ANGLE: Field Angle(1/10 peak): θ: 60°... - Page 14 SIZES: LIGHT OUTPUT: lux(W) 1019 lux(B) 1092 lux(G) lux(R) lux(RGBW) 2669 DISTANCE(m) DIAMETER(m) 12.5 10.4...
-
Page 15: Circuit Diagram And Pcb Connections
9. CIRCUIT DIAGRAM AND PCB CONNECTIONS ● CIRCUIT DIAGRAM... -
Page 16: Pcb Connections
●PCB CONNECTIONS Master Board （P/N230060494——Version with wireless function，P/N230060496——Version without wireless function） Name Optical sensor power supply signal input PWM signal Wireless board thermal switch Slaves （P/N230060486） Name LED driver power supply PWM signal input... -
Page 17: Component Order Codes
10. COMPONENT ORDER CODES Name Code No. Remarks Power Switch 192010201 LED light source 150020300 LED Driver Board 230060486 230060494 Only for version with wireless control LCD master board 230060496 Only for version without wireless control Reflector 060060071 Front Glass Panel 080090114 Transparent Display Cover 290190109... - Page 19 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020369...
