15-7 [:SENSe] Subsystem

15-7 [:SENSe] Subsystem
The commands in this subsystem relate to device-specific parameters, not signal-oriented
parameters.
[:SENSe]:AFPanalyzer:AVERage:COUNt <avg count>
[:SENSe]:AFPanalyzer:AVERage:COUNt?
Title: Measurement Average
Description: Sets the average count for the measurement data in the summary mode.
Parameter: <number>
Range: 1 to 65535
Front Panel
Access: Shift-4 (Measure), Average (only in Summary mode)
[:SENSe]:AFPanalyzer:DEMod:DATA?
Title: Summary data
Description: This query returns the measurement values in the Summary view. The
Front Panel
Access: Shift-4 (Measure), Audio Spectrum/Waveform.
[:SENSe]:AFPanalyzer:DEMod:MODE RFSP|AFSP|AFWV|SUMMary
[:SENSe]:AFPanalyzer:DEMod:MODE?
Title: Demodulation Mode
Description: This command sets the demodulation mode (graph type) to RF
Parameter: RFSP|AFSP|AFWV|SUMMary
Default Value: RFSP
Example: To set the demodulation mode to Audio Waveform:
Front Panel
Access: Shift-4 (Measure).
15-14
The query format of this command returns the value only in the
summary mode. The query format returns nothing in other
measurement modes.
order of the values are as follows:
<Modulation rate> in Hz, <RMS Deviation> in % or Hz or Rad
depending on the demod type, <Peak-Peak/2 Dev> in % or Hz or Rad
depending on the demod type, <SINAD> in dB, <THD> in % and
<Distortion> in %. All values are comma separated.
spectrum (RFSP) or Audio Spectrum (AFSP) or Audio
Waveform (AFWV) or Summary.
SENSe:AFPanalyzer:DEMod:MODE AFWV
PN: 10580-00341 Rev. C
Chapter 15 — AM/FM/PM Commands
