Figure 2: Signal of WWAN Module for UTMS Channels.
3. TEST Procedure
Power-up the EUT until it has completed its boot up process. Place the EUT in building and check the
UMTS/HSDPA signal intensity. Connect to Internet through UMTS/HSDPA channel. Check the link
speed if bandwidth is 7.2Mbps. Download a 10Mbytes test file from Internet. Record the results from
the link states. Make sure it has no any error while downloading.
Figure 3: Link Speed of WWAN Module for UMTS/HSDPA Channels.
53
