(2) External connector specification

2.1 POWER IN connector:

A. Connector size: 1 X 3 = 3 Pin
B. Connector location: PWR2
C. Connector pin definition
Pin
1
GND
2
DC_IN
3
IGNITION
2.2 POWER BUTTON connector:
A. Connector size: 6 Pin
B. Connector location: SW1
C. Connector pin definition
Pin
1
GND
3
PWRBT#
A1
LEN_N
NH1
NH2
PHOENIX 5mm-F-90D
Signal
SW1
1
2
1
2
4
3
4
3
A1
C1
A1
C1
MH1
MH2
MH1
MH2
PUSH SW_LED_BR
Signal
Pin
C1
PWR2
3
2
1
Signal
2
PWRBT#
4
GND
LED_P
11
1
3
