2.9 USB connector:
A. Connector size: USB TYPEA
B. Connector location: USB1
C. Connector pin definition
Pin
1 5VSB_USB
3 USB2_P
5 5VSB_USB
7 USB3_P

2.10 Audio connector:

A. Connector size: Phone Jack
B. Connector location: Audio2
C. Connector pin definition
Pin
1 FRONT_OUT_L
3 NC
5 GND
USB1
1
VCC VCC
2
DATA1- DATA-
3
DATA1+ DATA+
4
GND GND
9
MGND MGND
10
MGND MGND
2USB-F-90
Signal
LOUT1
5
4
3
1
6
2
AUDIO_PHONE-F-90
Signal
5
6
7
8
11
12
Pin Signal
2 USB2_N
4 GND
6 USB3_N
8 GND
Pin Signal
2 FRONT-JD
4 FRONT_OUT_R
6 GND
