Step 5. Take the Ipex Connector and

press on the wifi module as

shown in the picture.(Wifi)

Step 6. Take the Ipex Connector and

press on the 3G module as

shown in the picture. (3G)

Step 7. Take the Ipex Connector and

press on the GPS module as

shown in the picture. (GPS,

only support passive Antenna)
