  • Page 1 EMBEDDED COMPUTING User’s manual...
  • Page 2 Disclaimer SINTRONES® Technology Corp. shall not be liable for any incidental or consequential damages resulting from the performance or use of this product. SINTRONES® Technology Corp. makes no representation or warranty regarding the content of this manual.
  • Page 3 SBOX-2320 Manual Safety Information Read the following precautions before setting up a SINTRONES Product. Electrical safety  To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.  When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.
  • Page 4 SBOX-2320 Manual CAUTION Incorrectly replacing the battery may damage this computer. Replace only with the same or its equivalent as recommended by SINTRONES® Technology Corp. Dispose used battery according to the manufacturer's instructions. Technical Support Please do not hesitate to call or e-mail our customer service when you still cannot fix the problems.

  • Page 5: Table Of Contents

    SBOX-2320 Manual Content Introduction ..........................6  Specification..........................6 Illustration (MB/System) ......................8  Mainboard ..........................8  System ............................9 Architecture ..........................10 Principal component Specification ....................10  CPU ............................10 boot up the system ........................11 Internal Connector ........................12 ...
  • Page 6 SBOX-2320 Manual  AUDIO connector ........................23 System Introduction ........................24  I/O Panel ..........................24  Opening Chassis ........................25  Installing Memory ........................27  Installing MINI PCIe Expansion Card (MINICARD1) ..............28  Installing MINI PCIe Expansion Card (MINICARD2) ..............29 ...

  • Page 7: Introduction

    SBOX-2320 Manual INTRODUCTION Specification System Intel N3710 Quad Core CPU up to 2.56HGz Intel N3160 Quad Core CPU up to 2.24HGz Intel N3060 Dual Core CPU up to 2.48HGz Memory 1 x DDR3L-1600 SO-DIMM up to 8GB Graphics Intel HD Graphics...
  • Page 8 SBOX-2320 Manual Qualification Certifications CE, FCC Class A Environment Operating Temp. -30 ~ 60ºC (SSD), ambient w/ air Storage Temp. -40 ~ 85ºC Relative Humidity 10 ~ 95% @ 40ºC (non-condensing) Vibration (random) DC 9-36V Input with Reverse Polarity OCP and OVP Protection...

  • Page 9: Illustration (Mb/System)

    SBOX-2320 Manual ILLUSTRATION (MB/SYSTEM) Mainboard...

  • Page 10: System

    SBOX-2320 Manual System...

  • Page 11: Architecture

    SBOX-2320 Manual ARCHITECTURE PRINCIPAL COMPONENT SPECIFICATION Chip Description Intel 1. Power consumption: Core Processor Thermal Symbol Frequency/ Unit CPU Core Cache Number Design Power N3710 Up to 4 Core 2.56GHz N3160 Up to 4 Core 2.24GHz N3060 Up to 2 Core...

  • Page 12: Boot Up The System

    SBOX-2320 Manual BOOT UP THE SYSTEM 1. Connect the Two Pin Terminal Block to BOX PC (Positive and Negative) 2. Press the POWER button to boot up. Power adapter and DC Jack cable are the options...

  • Page 13: Internal Connector

    SBOX-2320 Manual INTERNAL CONNECTOR VGA Connector Connector location: VGA1 Connector size: 2 X 8 = 16 Pin Connector type: JST-2.0mm-M-180 USB Connector Connector location: USB2 Connector size: 2 X 4= 8Pin Connector type: JST-2.0mm-M-180...

  • Page 14: Gpio Connector

    SBOX-2320 Manual Connector location: USB3 Connector size: 2 X 4= 8Pin Connector type: JST-2.0mm-M-180 GPIO Connector Connector location: GPIO1 Connector size: 2 X 5 = 10 Pin Connector type: JST-2.0mm-M-180...

  • Page 15: Uart And Gpio Connector

    SBOX-2320 Manual UART and GPIO Connector Connector location: UART1 Connector size: 2 X 5 = 10 Pin Connector type: JST-2.0mm-M-180 LED Connector Connector location: LED1 Connector size: 2 X 5 = 10 Pin Connector type: JST-2.0mm-M-180...

  • Page 16: Com Port Connector

    SBOX-2320 Manual COM Port Connector Connector location: COM1 Connector size: 2 X 5 = 10 Pin Connector type: JST-2.0mm-M-180 Connector location: COM2 Connector size: 2 X 5 = 10 Pin Connector type: JST-2.0mm-M-180...
  • Page 17 SBOX-2320 Manual Connector location: COM3 Connector size: 2 X 5 = 10 Pin Connector type: JST-2.0mm-M-180 Connector location: COM4 Connector size: 2 X 5 = 10 Pin Connector type: JST-2.0mm-M-180...

  • Page 18: Audio Connector

    SBOX-2320 Manual AUDIO Connector Connector location: AUDIO1 Connector size: 1 X 10 = 10Pin Connector type: JST-2.0mm-M-180 SATA Connector Connector location: SATA1 Connector size: 1 X 7 = 7Pin Connector type: SATA 1.27mm-M-180D...

  • Page 19: Mini Pci-E Connector

    SBOX-2320 Manual Connector location: SATA2 Connector size: 1 X 7 = 7Pin Connector type: SATA 1.27mm-M-180D Mini PCI-E connector Connector location: MINICARD1 Connector size: 2 X 26 = 52 Pin Connector type: MINI PCI-E CON 9.2mmH...

  • Page 20: Power Input Connector

    SBOX-2320 Manual Connector location: MINICARD2 Connector size: 2 X 26 = 52 Pin Connector type: MINI PCI-E CON 9.2mmH Power Input Connector Connector location: SPWR1 Connector size: 1 X 4 = 4 Pin Connector type: WAFER 2.54mm-M-180...

  • Page 21: Sata Power Connector

    SBOX-2320 Manual SATA Power Connector Connector location: SPWR1 Connector size: 1 X 4 = 4 Pin Connector type: WAFER 2.54mm-M-180 Connector location: SPWR2 Connector size: 1 X 3 = 3 Pin Connector type: WAFER 2.54mm-M-180...

  • Page 22: External Connector Specification

    SBOX-2320 Manual EXTERNAL CONNECTOR SPECIFICATION USB Connector Connector location: USB1 Connector size: 18Pin Connector type: Type A LAN connector Connector location: LAN1 Connector size: 16 Pin Connector type: RJ45 + LED...

  • Page 23: Dvi-I Connector

    SBOX-2320 Manual Connector location: LAN2 Connector size: 16 Pin Connector type: RJ45 + LED DVI-I connector Connector location: DVI-I1 Connector size: 30 Pin Connector type: DVI-I...

  • Page 24: Hdmi Connector

    SBOX-2320 Manual HDMI connector Connector location: HDMI1 Connector size: 19 Pin Connector type: HDMI AUDIO connector Connector location: LOUT1 Connector size: 6Pin Connector type: PHONE JACK...

  • Page 25: System Introduction

    SBOX-2320 Manual SYSTEM INTRODUCTION I/O Panel...

  • Page 26: Opening Chassis

    SBOX-2320 Manual Opening Chassis Remove the four screws on the Back Cover as figure 1.
  • Page 27 SBOX-2320 Manual Front Panel/Rear Panel figure Remove the screws on the Front Panel (four screws) and Rear Panel (four screws) and open the Top Cover as figure 2.

  • Page 28: Installing Memory

    SBOX-2320 Manual Installing Memory Hold the Memory with its notch aligned with the Memory socket of the board and insert it at a 30-degree angle into the socket as figure 1. Press down on the Memory so that the tabs of the socket lock on both sides of the...

  • Page 29: Installing Mini Pcie Expansion Card (Minicard1)

    SBOX-2320 Manual Installing MINI PCIe Expansion Card (MINICARD1) Hold the Module with its notch aligned with the socket of the board and insert it at a 30-degree angle into the socket as shown in the picture. Secure the card with screw(s) as figure 2 and finish as figure 3.

  • Page 30: Installing Mini Pcie Expansion Card (Minicard2)

    SBOX-2320 Manual Installing MINI PCIe Expansion Card (MINICARD2) Hold the Module with its notch aligned with the socket of the board and insert it at a 30-degree angle into the socket as shown in the picture. Secure the card with screw(s) as figure 2 and finish as figure 3.

  • Page 31: Installing Internal Antenna Cable

    SBOX-2320 Manual Installing Internal Antenna Cable Take the SMA Connector (A) and plug into IO Panel (D). Put the Washer(B) into the SMA Connector (A), then put the O-ring (C) to SMA Connector (A) and tighten as shown in the picture.

  • Page 32: Installing Sim Card

    SBOX-2320 Manual Installing SIM Card Use thin stick to push the button, then take the holder and put your SIM Card into the Take the SIM card holder and Insert it into the socket Attention: Please cut the main power when you insert the SIM, otherwise the...

  • Page 33: System Resource

    SBOX-2320 Manual SYSTEM RESOURCE GPIO & Delay Time Setting GPIO and Ignition Control Register The General Purpose I/O is an interface available on some devices. These can read digital signals from other parts of a circuit, or output to control other devices. At GPIO control register, the GPI is use to receive data, the GPO is set data to send.
  • Page 34 SBOX-2320 Manual GPIO5 Output Enable Register – Index A0h Name R/W Defaul Description GPIO57_OE 0 : GPIO57 is input 1 : GPIO57 is output GPIO56_OE 0 : GPIO56 is input 1 : GPIO56 is output GPIO55_OE 0 : GPIO55 is input...
  • Page 35 SBOX-2320 Manual GPIO5 Pin Status Register – Index A2h Name R/W Defaul Description GPIO57_ST GPIO57 pin status. GPIO56_ST GPIO56 pin status. GPIO55_ST GPIO55 pin status. GPIO54_ST GPIO54 pin status. GPIO53_ST GPIO53 pin status. GPIO52_ST GPIO52 pin status. GPIO51_ST GPIO51 pin status.
  • Page 36 SBOX-2320 Manual GPIO50_DRV_E GPIO57 Drive Enable 0 : GPIO50 is open drain. 1 : GPIO50 is push pull. I/O port: I/O port: 0xA30 (base address) for Control Register (Read 0xF2h bit 3) 0xA31 (base address) for Control Data Value Ignition...

  • Page 37: Bios

    SBOX-2320 Manual BIOS Enter The BIOS Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press (DEL) key to enter Setup. Press DEL to enter SETUP If the message disappears before you respond and you still wish to enter Setup, restart the system by turning it OFF and On or pressing the RESET button.
  • Page 38 SBOX-2320 Manual Control Keys Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press (DEL) key to enter Setup. Move to the previous item <↑> Move to the next item <↓>...

  • Page 39: Main

    SBOX-2320 Manual If you find a right pointer symbol (as shown in the right view) appears to the left of certain fields that means a sub-menu can be launched from this field. A sub- menu contains additional options for a field parameter. You can use arrow keys ( ↑↓...

  • Page 40: Advanced

    SBOX-2320 Manual This setting allows you to set the system time. The time format is <Hour> <Minute> <Second>. Advanced CPU Configuration...
  • Page 41 SBOX-2320 Manual » Limit CPUID Maximum The CPUID instruction of some newer CPUs will return a value greater than 3. The default is Disabled because this problem does not exist in the Windows series operating systems. If you are using an operating system other than Windows, this problem may occur.
  • Page 42 SBOX-2320 Manual » Serial Port 0/1/2/3 Enable or Disable Select an Enable or Disable for the specified serial ports. » COM1 RS232/422/485 Select...
  • Page 43 SBOX-2320 Manual RS422 need to choice Termination and slect Enabled...
  • Page 44 SBOX-2320 Manual » COM2 RS232/422/485 Select RS422 nee to choice Termination and select Enabled...
  • Page 45 SBOX-2320 Manual » Watch Dog Function » GPIO Configuration...
  • Page 46 SBOX-2320 Manual » GPO 0/ 1/ 2/ 3/ Data These settings configure special GPIO data. Hardware Health Configuration These items display the current status of all monitored hardware devices/components such as voltages, temperatures and all fans' speeds.

  • Page 47: Chipset

    SBOX-2320 Manual Chipset PCH-IO Configuration...
  • Page 48 SBOX-2320 Manual System Agent (SA) Configuration » Graphics Configuration...
  • Page 49 SBOX-2320 Manual...
  • Page 50 SBOX-2320 Manual...

  • Page 51: Boot

    SBOX-2320 Manual Boot » 1st/2nd/3rd Boot Device The items allow you to set the sequence of boot devices where BIOS attempts to load the disk operating system. » Try Other Boot Devices Setting the option to [Enabled] allows the system to try to boot from other...
  • Page 52 SBOX-2320 Manual » Hard Disk Drives, CD/DVD Drives, USB Drives These settings allow you to set the boot sequence of the specified devices.

  • Page 53: Security

    SBOX-2320 Manual Security » Administrator Password Administrator Password controls access to the BIOS Setup utility. These settings allow you to set or change the administrator password. » User Password User Password controls access to the system at boot. These settings allow you to set or change the user password.

  • Page 54: Exit

    SBOX-2320 Manual Exit » Save Changes and Exit Save changes to CMOS and exit the Setup Utility. » Discard Changes and Exit Abandon all changes and exit the Setup Utility. » Discard Changes Abandon all changes and continue with the Setup Utility.

  • Page 55: Packing List

    SBOX-2320 Manual PACKING LIST System Item Part Number Module Name 762320011000 SBOX-2320-N0 Barebone 762320011001 SBOX-2320-N1 Barebone 762320011002 SBOX-2320-N2 Barebone 762320011003 SBOX-2320-4S-N0 Accessory Picture Part Number Module Name Q’ty 326910029661 CABLING MC101-508-02GA1 F 351103040250 Screw F Type M3*4L ISO BK...
