Sintrones VBOX-3200 User Manual page 14

D. Connector pin definition (RS-422)
Pin
1 COM1_TXD-
3 COM1_TXD+
5 NC
7 NC
9 NC
E. Connector pin definition (RS-485)
Pin
1 COM1_TXD-/RXD-
3 NC
5 NC
7 NC
9 NC
2.7 DVI-I connector:
A. Connector size: DVI-I
B. Connector location: DVID2
Signal
Signal
DVID2
17 TX0-
9 TX1-
18 TX0+
10 TX1+
19 0/5 Shield 2/4 Shield
11 1/3 Shield
20 TX5-
12
TX3-
21 TX5+
13 TX3+
22 TX Clk Shield
14 +5V Power
23 TX Clk+
15 Ground
24 TX Clk- Analog VSync
16 HotPlugDet
C3 Analog BLUE Analog RED
C6 Analog Ground Analog Ground
C4 Analog HSync Analog GREEN
DVI-I CON-90
Pin Signal
2 COM1_TXD+
4 COM1_RXD-
6 NC
8 NC
Pin Signal
2 COM1_TXD+/RXD+
4 NC
6 NC
8 NC
TX2- 1
TX2+ 2
3
TX4- 4
TX4+ 5
DDC CLK 6
DDC DATA 7
8
C1
C5
C2
MGND H1
H2
MGND
H3
H4
14
