Sintrones VBOX-3600 User Manual

Hide thumbs Also See for VBOX-3600:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Document Name VBOX-3600 User Manual
Version
1.0
Reversion History :
Reversion
From
To
1.0
May 17, 2013 Initial document issued
VBOX-3600
In-Vehicle Computing
User's Manual
Version 1.0
Date
Document No. UM2013360010
Date
Notes
1
May. 17, 2013
Author(s)
Stanley Chou

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VBOX-3600 and is the answer not in the manual?

Questions and answers

Related Manuals for Sintrones VBOX-3600

Summary of Contents for Sintrones VBOX-3600

  • Page 1 VBOX-3600 In-Vehicle Computing User's Manual Version 1.0 Document Name VBOX-3600 User Manual Document No. UM2013360010 Version Date May. 17, 2013 Reversion History : Reversion Date Notes Author(s) From May 17, 2013 Initial document issued Stanley Chou...
  • Page 2 Other brands and product names used herein are for identification purposes only and may be trademarks of their respective owners. Disclaimer SINTRONES® Technology Corp. shall not be liable for any incidental or consequential damages resulting from the performance or use of this product. SINTRONES® Technology Corp. makes no representation or warranty regarding the content of this manual.

  • Page 3: Safety Information

    • If you encounter technical problems with the product, contact a qualified service technician or your retailer. CAUTION Incorrectly replacing the battery may damage this computer. Replace only with the same or its equivalent as recommended by SINTRONES® Technology Corp. Dispose used battery according to the manufacturer's instructions.

  • Page 4: Table Of Contents

    Table of contents page (1) Introduction 1.1 Model Specifications 1.2 VBOX-3600 Illustration (Main board, System) (2) Internal connector specification 2.1 VGA JST connector 2.2 USB JST connector 2.3 USB JST connector 2.4 GPIO JST connector 2.5 UART JST connector 2.6 LED JST connector (LED1) 2.7 LED JST connector (LED2)
  • Page 5 3.10 DB9 connector: (COM2) 3.11 PHONE JACK: (MIC IN) 3.12 PHONE JACK: (LINE OUT) 3.13 ATX 6PIN connector : (POWER OUT) (4) System Installation 4.1 System Introduction 4.2 Opening Chassis 4.3 Installing Memory 4.4 Installing MINI PCIe Expansion Card (PCIe 1, 3G Module only) 4.5 Installing MINI PCIe Expansion Card (PCIe 2) 4.6 Installing MINI PCIe Expansion Card (PCIe 3) 4.7 Installing MINI PCIe Expansion Card (PCIe 4, PCIe only)

  • Page 6: Model Specifications

    1.1 Model Specification System Intel Gen 3 Core i7-3517UE 1.7GHz Intel Gen 3 Core i3-3217UE 1.6GHz Intel Gen 3 Celeron Dual Core 1047E 1.4GHz 1 x DDR3 1066/1333/1600 MHz SO-DIMM up to 8 GB Memory QM77 Chipset Intel I210-AT Gb/s Ethernet Controllers Onboard LAN Chipset Support PXE and WOL Realtek ALC662 HD Codec onboard...
  • Page 7 Graphics Intel® HD Graphics 4000 DirectX Video Acceleration (DXVA) for Accelerating Video Graphics Processing - Full AVC/VC1/MPEG2 HW Decode Supports DirectX 11/10.1/10/9 and OpenGL 3.0 Up to 1920 x 1200 Resolution Qualification CE, FCC Class A, eMark Certifications 4 x RS-232 ( COM1,2 with RS-422/485, RS-485 Support Auto Direction Control Serial Port 4 x USB 2.0 Ports on Front I/O...

  • Page 8: Vbox-3600 Illustration (Main Board, System)

    1.2 VBOX-3600 Illustration Main board...
  • Page 9 System...

  • Page 10: Vga Jst Connector

    Internal connector specification 2.1 VGA connector Connector 2 X 8 = 16 Pin size Connector JST-2.0mm-M-180 type Connector VGA1 location Connector Signal Signal GREEN definition BLUE CER_DET DAC_SDA HSYNC VSYNC DAC_SCL Connector...

  • Page 11: Usb Jst Connector

    2.2 USB connector Connector 2 X 4 = 8 Pin size Connector JST-2.0mm-M-180 type Connector USB2 (Co-layout with DVI-I1) location Connector Signal Signal 5VSB 5VSB definition USB_7N USB_7P Connector...

  • Page 12: Usb Jst Connector

    2.3 USB connector Connector 2 X 4 = 8 Pin size Connector JST-2.0mm-M-180 type Connector USB3 (Co-layout with MINICARD3) location Connector Signal Signal 5VSB 5VSB definition USB_6N USB_6P Connector...

  • Page 13: Gpio Jst Connector

    2.4 GPIO connector Connector 2 X 5 = 10 Pin size Connector JST-2.0mm-M-180 type Connector GPIO1 location Connector Signal Signal GPI0 GPI1 definition GPI2 GPI3 GPO0 GPO1 GPO2 GPO3 +12V Connector...

  • Page 14: Uart Jst Connector

    2.5 UART connector Connector 2 X 5 = 10 Pin size Connector JST-2.0mm-M-180 type Connector UART1 (COM5 for GPS Module when VDB-800 is installed) location Baud Rate : 9600 Connector Signal Signal COM5_RX definition COM5_TX Connector...

  • Page 15: Led Jst Connector (Led1)

    2.6 LED connector Connector 2 X 2 = 4 Pin size Connector LED WITH HOUSING type Connector LED1 location Connector Signal Signal 3.5G_LED_P UPS_LED_P definition 3.5G_LED_N UPS_LED_N Connector...

  • Page 16: Led Jst Connector (Led2)

    2.7 LED connector Connector 2 X 2 = 4 Pin size Connector LED WITH HOUSING type Connector LED2 location Connector Signal Signal ACC_LED_P HDD_LED_P definition ACC_LED_N HDD_LED _N Connector...

  • Page 17: Com Port Jst Connector: (Com3)

    2.8 COM connector Connector 2 X 5 = 10 Pin size Connector JST-2.0mm-M-180 type Connector COM3 location Connector Signal Signal COM3_DCD COM3_RXD definition COM3_TXD COM3_DTR COM3_DSR COM3_RTS COM3_CTS COM3_RI Connector...

  • Page 18: Com Port Jst Connector: (Com4)

    2.9 COM connector Connector 2 X 5 = 10 Pin size Connector JST-2.0mm-M-180 type Connector COM4 location Connector Signal Signal COM4_DCD COM4_RXD definition COM4_TXD COM4_DTR COM4_DSR COM4_RTS COM43_CTS COM4_RI Connector...

  • Page 19: Audio Jst Connector

    2.10 AUDIO connector Connector 1 X 10 = 10 Pin size Connector JST-2.0mm-M-180 type Connector AUDIO1 location Connector Signal definition MIC_IN_ L MIC_IN_R MIC-JD Connector...

  • Page 20: Sata 7Pin Connector: (Sata3)

    2.11 SATA connector Connector 1 X 7 = 7 Pin size Connector SATA 1.27mm-M-180D type Connector SATA DOM1 location Connector Signal definition SATA_TXP2 SATA_TXN2 SATA_RXN2 SATA_RXP2 Connector...

  • Page 21: Sata 7Pin Connector: (Sata1)

    2.12 SATA connector Connector 1 X 7 = 7 Pin size Connector SATA 1.27mm-M-180D type Connector SATA1 location Connector Signal Signal definition SATA_TXP0 SATA_TXN0 SATA_RXN0 SATA_RXP0 Connector...

  • Page 22: Sata 7Pin Connector: (Sata2)

    2.13 SATA connector Connector 1 X 7 = 7 Pin size Connector SATA 1.27mm-M-180D type Connector SATA2 location Connector Signal Signal definition SATA_TXP1 SATA_TXN1 SATA_RXN1 SATA_RXP1 Connector...

  • Page 23: Mini Pci-E Slot: (Minicard1)

    2.14 Mini PCI-E connector Connector 2 X 26 = 52 Pin size Connector MINI PCI-E CON 9.2mmH type Connector MINICARD1 location Connector Signal Signal PCIE_WAKE# 3VSB definition +1.5V MINICARD1_CLKREQ# UIM_PWR UIM_DAT UIM_CLK UIM_RST MINICARD 1_DIS# PCIE_RST# 3VSB +1.5V SMB_CLK SMB_DATA USB_4N USB_4P 3VSB...
  • Page 24 Connector...

  • Page 25: Mini Pci-E Slot: (Minicard2)

    2.15 Mini PCI-E connector Connector 2 X 26 = 52 Pin size Connector MINI PCI-E CON 9.2mmH type Connector MINICARD2 location Connector Signal Signal PCIE_WAKE# 3VSB definition +1.5V MINICARD2_CLKREQ# UIM_PWR UIM_DAT PCIE_MCARD2_CLK_N UIM_CLK PCIE_MCARD2_CLK_P UIM_RST MINICARD2_DIS PCIE_RST# PCIE_MCARD2_RX_N 3VSB PCIE_MCARD2_RX_P +1.5V SMB_CLK PCIE_MCARD2_TX_N...
  • Page 26 Connector...

  • Page 27: Mini Pci-E Slot: (Minicard3)

    2.16 Mini PCI-E connector Connector 2 X 26 = 52 Pin size Connector MINI PCI-E CON 9.2mmH type Connector MINICARD3 location Connector Signal Signal PCIE_WAKE# 3VSB definition +1.5V MINICARD3_CLKREQ# PCIE_MCARD3_CLK_N PCIE_MCARD3_CLK_P MINICARD3_DIS PCIE_RST# PCIE_MCARD3_RX_N 3VSB PCIE_MCARD3_RX_P +1.5V SMB_CLK PCIE_MCARD3_TX_N SMB_DATA PCIE_MCARD3_TX_P USB_6N USB_6P...
  • Page 28 Connector...

  • Page 29: Mini Pci-E Slot: (Minicard4)

    2.17 Mini PCI-E connector Connector 2 X 26 = 52 Pin size Connector MINI PCI-E CON 9.2mmH type Connector MINICARD4 location Connector Signal Signal PCIE_WAKE# 3VSB definition +1.5V MINICARD4_CLKREQ# PCIE_MCARD4_CLK_N PCIE_MCARD4_CLK_P MINICARD4_DIS PCIE_RST# PCIE_MCARD4_RX_N 3VSB PCIE_MCARD4_RX_P +1.5V SMB_CLK PCIE_MCARD4_TX_N SMB_DATA PCIE_MCARD4_TX_P 3VSB 3VSB...
  • Page 30 Connector...

  • Page 31: Power In Connector

    2.18 POWER Input connector Connector 1 X 4 = 4 Pin size Connector WAFER 2.54mm-M-180 type Connector PWRIN1 location Connector Signal definition VIN (9-32V) IGNITION Connector...

  • Page 32: Sata Power Connector: (Spwr1)

    2.19 SATA power connector Connector 1 X 4 = 4 Pin size Connector WAFER 2.54mm-M-180 type Connector SPWR1 location Connector Signal definition +12V Connector...

  • Page 33: Ups Power Connector

    2.20 UPS power connector Connector 1 X 4 = 4 Pin size Connector WAFER 2.54mm-M-180 type Connector UPS1 location Connector Signal +12V definition +12V Connector...

  • Page 34: Usb3.0 Type A Connector

    External connector specification 3.1 USB connector Connector 8 Pin size Connector USB3.0 Type A type Connector USB3 location Connector Signal Signal 5VSB USB0_N definition USB0_P SSRX0_ON SSRX0_OP SSTX0_ON SSTX0_OP 5VSB USB1_N USB1_P SSRX1_ON SSRX1_OP SSTX1_ON SSTX1_OP Connector...

  • Page 35: Usb3.0 Type A Connector

    3.2 USB connector Connector 8 Pin size Connector USB3.0 Type A type Connector USB4 location Connector Signal Signal 5VSB USB2_N definition USB2_P SSRX2_ON SSRX2_OP SSTX20_ON SSTX2_OP 5VSB USB3_N USB3_P SSRX3_ON SSRX3_OP SSTX3_ON SSTX3_OP Connector...

  • Page 36: Rj45 Connector: (Lan1)

    3.3 LAN connector Connector 12 Pin size Connector RJ45+LED type Connector LAN1 location Connector Signal Signal LAN0_MDI0P LAN0_MDI0N definition LAN0_MDI1P LAN0_MDI2P LAN0_MDI2N LAN0_MDI1N LAN0_MDI3P LAN0_MDI3N LAN0_ACT# LAN0_ACTP LAN0_LINK# LAN0_LINKP Connector...

  • Page 37: Rj45 Connector: (Lan2)

    3.4 LAN connector Connector 12 Pin size Connector RJ45+LED type Connector LAN2 location Connector Signal Signal LAN1_MDI0P LAN1_MDI0N definition LAN1_MDI1P LAN1_MDI2P LAN1_MDI2N LAN1_MDI1N LAN1_MDI3P LAN1_MDI3N LAN1_ACT# LAN1_ACTPW LAN1_LINK# LAN1_LINKPW Connector...

  • Page 38: Rj45 Connector: (Lan3)

    3.5 LAN connector Connector 12 Pin size Connector RJ45+LED type Connector LAN3 location Connector Signal Signal LAN2_MDI0P LAN2_MDI0N definition LAN2_MDI1P LAN2_MDI2P LAN2_MDI2N LAN2_MDI1N LAN2_MDI3P LAN2_MDI3N LAN2_ACT# LAN2_ACTPW LAN2_LINK# LAN2_LINKPW Connector...

  • Page 39: Rj45 Connector: (Lan4)

    3.6 LAN connector Connector 12 Pin size Connector RJ45+LED type Connector LAN4 location Connector Signal Signal LAN3_MDI0P LAN3_MDI0N definition LAN3_MDI1P LAN3_MDI2P LAN3_MDI2N LAN3_MDI1N LAN3_MDI3P LAN3_MDI3N LAN3_ACT# LAN3_ACTPW LAN3_LINK# LAN3_LINKPW Connector...

  • Page 40: Db29 Connector: (Dvi-I)

    3.7 DVI-I connector Connector 50 Pin size Connector DVI-I type Connector DVI-I1 location Connector Signal Signal DVI_TX2_N DVI_TX2_P definition 5VSB +12V DVI_DDC_CLK DVI_DDC_DATA CRT_VSYNC DVI_TX1_N DVI_TX1_P USB_7N USB_7P DVI_HPD DVI_TX0_N DVI_TX0_P CRT_DAC_SDA CRT_DAC_SCL DVI_CLK_P DVI_CLK_N CRT_RED CRT_GREEN CRT_BLUE CRT_HSYNC CRT_DET Connector...

  • Page 41: Dp Connector

    3.8 DP connector Connector 20 Pin size Connector Display port type Connector location Connector Signal Signal DP2_LANE_0P definition DP2_LANE_0N DP2_LANE_1P DP2_LANE_1N DP2_LANE_2P DP2_LANE_2N DP2_LANE_3P DP2_LANE_3N DP2_AUX_EN# DP2_AUXP_CLK DP2_AUXN_DATA DP2_HPD DP2_VCC3 Connector...

  • Page 42: Db9 Connector: (Com1)

    3.9 COM connector Connector 9 Pin size Connector DSUB type Connector COM1 location Connector Signal Signal COM1_DCD / COM1_RXD definition (RS-485_TXD-/RXD-) (RS-485_TXD+/RXD+) COM1_TXD COM1_DTR COM1_DSR COM1_RTS COM1_CTS COM1_RI# Connector...

  • Page 43: Db9 Connector: (Com2)

    3.10 COM connector Connector 9 Pin size Connector DSUB type Connector COM2 location Connector Signal Signal COM2_DCD COM2_RXD definition (RS-485_TXD-/RXD-) (RS-485_TXD+/RXD+) COM2_TXD COM2_DTR COM2_DSR COM2_RTS COM2_CTS COM2_RI# Connector...

  • Page 44: Phone Jack: (Mic In)

    3.11 MIC connector Connector 6 Pin size Connector Phone Jack type Connector MIC1 location Connector Signal Signal MIC_OUT-L MIC-JD definition MIC_OUT-R Connector...

  • Page 45: Phone Jack: (Line Out)

    3.12 LINE OUT connector Connector 6 Pin size Connector Phone Jack type Connector LOUT1 location Connector Signal Signal FRONT_OUT_L FRONT-JD definition FRONT_OUT_R Connector...

  • Page 46: Atx 6Pin Connector : (Power Out)

    3.13 POWER OUT connector Connector 6 Pin size Connector ATX 6PIN type Connector PWROUT1 location Connector Signal Signal +12V +12V definition EXT_DI1 EXT_DI2 Connector...

  • Page 47: System Introduction

    4 System Installation 4.1 System Introduction  GPS Antenna SIM Card2 LAN1 LAN2 LAN3 LAN4 USB3.0 SIM Card1 Power Button 2.5" Storage Bay 3G Antenna WiFi/BT Antenna COM3 COM4/VIDEO IN WiFi/BT Antenna MIC Line Out COM1 COM2 DVI-I DC IN 12V OUTPUT...

  • Page 48: Opening Chassis

     4.2 Opening Chassis Step 1. Unscrew the six screws of the Back Cover as shown in the picture. Step 2. Unscrew the six screws of the Front Panel as shown in the picture. Step 3. Unscrew the six screws of the Rear Panel as shown in the picture.

  • Page 49: Installing Memory

     4.3 Installing Memory Step 1. Put Memory on this place as shown in the picture. Step 2. Hold the Memory with its notch aligned with the Memory socket of the board and insert it at a 30-degree angle into the socket as shown in the picture.

  • Page 50: Installing Mini Pcie Expansion Card (Pcie 1, 3G Module Only)

     4.4 Installing MINI PCIe Expansion Card (PCIe 1, 3G Module only) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture.

  • Page 51: Installing Mini Pcie Expansion Card (Pcie 2)

     4.5 Installing MINI PCIe Expansion Card (PCIe 2) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture.

  • Page 52: Installing Mini Pcie Expansion Card (Pcie 3)

     4.6 Installing MINI PCIe Expansion (PCIe 3) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture.

  • Page 53: Installing Mini Pcie Expansion Card (Pcie 4, Pcie Only)

     4.7 Installing MINI PCIe Expansion (PCIe 4, PCIe only) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture.

  • Page 54: Installing Internal Antenna Cable

     4.8 Installing Internal Antenna Cable Step 1. Take the SMA Connector and Plug into IO Panel as shown in the picture. Step 2. Put the Washer into the SMA Connector as shown in the picture. Step 3. Put the Oring to SMA Connector and tighten as shown in the picture.
  • Page 55 Step 5. Take the Ipex Connector and press on the wifi module as shown in the picture.(Wifi) Step 6. Take the Ipex Connector and press on the 3G module as shown in the picture. (3G) Step 7. Take the Ipex Connector and press on the GPS module as shown in the picture.

  • Page 56: Installing Sim Card

     4.9 Installing SIM Card Step 1. Use thin stick to push the button as shown in the picture. Step 2. Take the holder away from front panel as shown in the picture. Step 3. Put your SIM Card into the holder as shown in the picture.

  • Page 57: Installing Hdd

     4.10 Installing HDD Step 1. Put the HDD into HDD Holder as shown in the picture. Step 2. Screw two screws on both side as shown in the picture. Step 3. Push the HDD Holder into the socket as shown in the picture.
  • Page 58 Step 4. Fully insert the HDD Holder into the socket until a “click” is heard as shown in the picture. Step 5. Tighten to Storage Bracket screws as shown in the picture.

  • Page 59: Installing Battery Module

     4.11 Installing Battery Module Step 1. Accessories list Step 2. Fix the Tube with Screw A on the motherboard Step 3. Fix the Tube with Screw A to another hole. Step 4. Fix the Scew A from back side...
  • Page 60 Step 5. Tube Location check. Step 6. Connect the battery with motherboard on UPS location. Step 7. Fix the battery with Screw B. (Done)

  • Page 61: Ignition Power Management Quick Guide

    (5) System Resources 5.1 Ignition Power Management Quick Guide Startup/shutdown conditions from the IGNITION signal:  IGNITION startup signal must be valid during 3 sec. (anti noise protection).  IGNITION shutdown – IGNITION signal must be inactive during 3 Sec, then PIC controller initiate Power Button signal (OS must be set to shutdown from the Power Button).

  • Page 62: Power Management

    Ignition On/Off status detectable by SW  If the ignition is off and the system is still on after 3 Sec, VBOX-3600 will shut down automatically.  If the ignition is turned on again and the power-off delay is in progress, VBOX-3600 will cancel the delay function and will continue to operate normally.

  • Page 63: Gpio & Delay Time Setting

    5.2 GPIO & Ignition Register 5.2.1 GPIO and Ignition Control Register The General Purpose I/O is an interface available on some devices. These can read digital signals from other parts of a circuit, or output to control other devices. At GPIO control register, the GPI is use to receive data, the GPO is set data to send.
  • Page 65 I/O port: I/O port: 0xA35 (base address) for Control Register (Read 0xF2h bit 3) 0xA36 (base address) for Control Data Value Ignition Status 0 = Ignition off 1 = Ignition on Debug Command Line O A35 F2 I A36 // Check Bit 3 Status 5.2.2 WDT Setting I/O port: A10 (base address) + 05h and 06h...

  • Page 67: Super Io Configuration

    (6) BIOS 6.1 Super IO Configuration Select Serial Port Mode...

  • Page 68: Packing List

    (7) Packing List 7.1 Packing List Item Part Number Module Name 763600000100 VBOX-3600 System 370832001100 VBOX-3600 Mount Bracket 351103040250 Screw F Type M3*4L ISO BK 326710039661 CABLING PHOENIX CON MALE 3PIN Optional Part No. Vendor / Model Description LTE – DD 800MHz (Band 20) / 900MHz (Band 8) /2600MHz (Band 7) / 1800MHz (Band 3 ) / 2100MHz (Band 11) MHz DC-HSPA+1/HSPA+/HSUPA/HSDPA/UMTS –...
  • Page 69 Embedded u-blox6 GPS Mini PCIe Card Very high sensitivity (Tracking Sensitivity: -160 dBm) 50 Channels / Hot Start 1s / Warm Start 28s / Cold Start 28s 570800100109 VDB-800S AssistNow Online and Offline A-GPS Services,OMA SUPL Compliant Support NMEA 0183 V3.0 Update Rate 5 Hz (Max.) (GPS Active Antenna be included) Embedded u-blox6 GPS with...
  • Page 70 802.11n b/g 1x1 wifi plus Bluetooth combo PCIe half-size mini card, 570195090090 DHXA-195 WB195/AR9285+AR3011 (Wifi Antenna Kit be included) Ralink 802.11b/g/N, 2T2R,Mini PCIe Card (Full size) 570802010009 Q802XKN5F (Wifi Antenna Kit be included) Ralink 802.11b/g/N, 2T2R,Mini PCIe Card (Half size)(Wifi Antenna Kit 570802011009 Q802XKN5 be included)
  • Page 71 GPS-Passive-5M (Only for GOBI Series) 343235002000 GPS-Active-5M Active Antenna 5M / SMA male 221401280006 BAT-3600 Neosonic-Polymer 1100mAH 3S1P Battery kit for VBOX-3600 972009720000 Microsoft Windows Embedded Standard 2009 (Windows XP Embedded) 970000750000 Microsoft Windows XP Pro license fee 970007740000 Microsoft Windows®...
