- Page 1 USB-C Multiport Mini Dock USER MANUAL UH3232...
- Page 2 EMC Information Federal Communication Commission Interference Statement: This equipment has been tested and found to comply with the limits for a Class B digital service, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.
-
Page 3: Technical Support
UH3232 User Manual Online Registration International http://eservice.aten.com Telephone Support International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 United Kingdom 44-8-4481-58923 Technical Support For international online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com... -
Page 4: Package Contents
® Copyright © 2017 ATEN International Co., Ltd.® Manual Date: 2017-08-08 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 4 -... - Page 5 This means that when the UH3232 is connected to a computer and a device with an incompatible alternate mode is connected, it alerts you with support details, instead of failing in silence.
- Page 6 Features Connects a USB-C or Thunderbolt™ 3 computer to an HDMI / VGA display, Ethernet cable and USB Type-A peripheral USB 3.1 Gen 1 port with data transfer rates up to 5 Gbps Superior video resolutions up to 3840 x 2160 @ 30 Hz (HDMI) or 2048 x 1152 @ 60 Hz (VGA) Supports HDMI 1.4b @ 4K (UHD) resolutions Gigabit Ethernet port...
-
Page 7: System Requirements
System Requirements Hardware 1 USB-C enabled computer Software Windows® 10 (32-bit / 64-bit) and above Mac OS X 10.12 and later* - 7 -... - Page 8 Components UH3232 Front Component Description USB-C Cable This cable connects to a USB-C enabled computer. Gigabit LAN Port Plug an Ethernet cable into this port to provide a network connection. USB 3.1 Gen 1 Plug a USB 3.0/2.0/1.1 peripheral device to this port.
- Page 9 2. Make sure that all devices you will be installing are properly grounded. Hardware To setup the UH3232, use the diagram on the next page (the numbers in the diagram correspond with the numbered instructions below), and do the following: 1.
- Page 10 - 10 -...
- Page 11 Configuration and Settings Support VGA Resolutions Horizontal Vertical Frame Rate 2048 1152 60 Hz 1920 1080 60 Hz 1366 60 Hz 1360 60 Hz 1280 60 Hz 1280 60 Hz 1024 60 Hz Support HDMI Resolutions Horizontal Vertical Frame Rate 3840 2160 30 Hz...
-
Page 12: Specifications
Specifications Function UH3232 Computer Connections Connectors Computer 1 x USB-C Male (Black) Device 1 x USB 3.1 Gen 1 Type A Female (Blue) Video Output 1 x HDMI Female (Black) 1 x VGA Female (Black) 1 x Gigabit Ethernet Female (Black) - Page 13 ATEN will provide a repair service, without charge, during the Warranty Period. If a product is defective, ATEN will, at its discretion, have the option to (1) repair said product with new or repaired components, or (2) replace the entire product with an identical product or with a similar product which fulfills the same function as the defective product.
