- Page 1 USB-C Dual-View Mini Dock USER MANUAL UH3233...
-
Page 2: Emc Information
© Copyright 2021 ATEN® International Co., Ltd. Manual Date: 2021-01-06 ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other brand names and trademarks are the registered property of their respective owners. The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. - Page 3 Telephone Support International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 1-949-428-1111 Technical Support For international online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com For North American technical support: Email Support support@aten-usa.com...
-
Page 4: Package Contents
Package Contents The UH3233 USB-C Dual-HDMI Mini Dock package contains the following items: 1 UH3233 USB-C Dual-HDMI Mini Dock 1 USB-C to USB-C Cable 1 User Instructions* Check to make sure that all the components are present and that nothing got damaged in shipping. - Page 5 Overview The ATEN UH3233 USB-C Dual-HDMI Mini Dock transforms your USB-C device into a dual monitor workstation, and is compliant with the latest USB 3.1 Gen 1 Type-C specifications. The UH3233 can route video from a source device to one HDMI...
- Page 6 Features Connects a computer to two HDMI monitors with Dual-View output USB 3.1 Gen 1 compliant Supports 4K (UHD) resolution via single display output* Supports dual-display video output up to 1920 x 1080 simultaneously* USB 3.1 Gen 1 port with data transfer rates up to 5 Gbps ...
-
Page 7: System Requirements
System Requirements Hardware A USB Type-C or Thunderbolt™ 3 USB Type-C compatible computer* Two HDMI monitors Note: 1. For video output to work through a USB-C port, it must support DP Alt Mode. 2. For Dual-View to work, the computer’s onboard graphics module or video source requires DisplayPort 1.2 with MST+HBR2 compatibility to support video output under extended mode. - Page 8 Components UH3233 Front View Rear View Component Description Power / Status This LED lights Blue to indicate the UH3233 is powered on, or Orange to indicate that the UH3233 isn’t receiving sufficient power from the computer to supply power to the device connected to the USB 3.1 Gen 1 Type-C port.
-
Page 9: Installation
Installation 1. Make sure that the power to any device that you connect to the installation has been turned off. 2. Make sure that all devices you will be installing are properly grounded. To set up the UH3233, use the diagram on the next page (the numbers in the diagram correspond with the numbered instructions below), and do the following: 1. - Page 10 - 10 -...
-
Page 11: Specifications
Specifications Function UH3233 Computer Connections Connectors Computer 1 x USB-C Female (Black) Device 1 x USB 3.1 Gen 1 Type A Female (Blue) Video Output 2 x HDMI Female (Black) LEDs Power 1 (Blue/Orange) Video HDMI 3840 x 2160 @ 30 Hz Single View Resolution HDMI... -
Page 12: Limited Warranty
What is covered by the Limited Hardware Warranty ATEN will provide a repair service, without charge, during the Warranty Period. If a product is detective, ATEN will, at its discretion, have the option to (1) repair said product with new or...
