Parts List; Hardware List; Tools Needed - Premier Mounts PWM-503 Installation Manual

Parts List

HARDWARE LIST

TOOLS NEEDED

Phillips screwdriver
o
Drill gun
o
Soft material or a blanket
o
Pencil
o
¼" drill bit
o
Level
o
Measuring tape
o
Wrench with a 1/2" socket
o
Stud finder
o
CEILING ADAPTERS (OPTIONAL)
PCA-1 – 4.5" Ceiling adapter mates directly to the PSB-TBP tilt back plate
o
PSA-1 – Height adjustable ceiling adapter adjustable range 24" to 46"
o
PCA-1
Ceiling adapter
QTY
6 5/16" Dia
1
1
2 M6 x 12 (mm) Phillip security
screws
1
6 M8 x 20 Phillip screws
SIZE DESCRIPTION
Lag bolts
Mounting bracket
PSB-TBP tilt back plate
Used for additional security on
tilt mounts, mobile carts, floor
stands and ceiling mounts
Installations instructions
Mount hardware
PSA-1
Height adjustable
ceiling adapter
- 5 -
