Premier Mounts Clevis Mount PCM-MS2 Installation Instructions Manual

Universal flat panel mount
Hide thumbs Also See for Clevis Mount PCM-MS2:

Advertisement

NORTH AMERICA
3130 East Miraloma Avenue
Anaheim, CA 92806 USA
Other Locations – Phone: (001)-714-632-7100; Fax: (001)-714-632-1044
©Premier Mounts 2009
9531-000-501-04

INSTALLATION INSTRUCTIONS

Universal Flat Panel Mount
USA and Canada –
Phone: 800-368-9700
Fax: 800-832-4888
PCM-MS2
EUROPE
Swallow House,
Shilton Industrial Estate,
Shilton, Coventry, England CV79JY
Phone: +44 (0) 2476 614700
Fax: +44 (0) 2476 614710

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Clevis Mount PCM-MS2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Premier Mounts Clevis Mount PCM-MS2

  • Page 1: Installation Instructions

    NORTH AMERICA 3130 East Miraloma Avenue Anaheim, CA 92806 USA USA and Canada – Phone: 800-368-9700 Fax: 800-832-4888 Other Locations – Phone: (001)-714-632-7100; Fax: (001)-714-632-1044 ©Premier Mounts 2009 9531-000-501-04 PCM-MS2 Universal Flat Panel Mount EUROPE Swallow House, Shilton Industrial Estate,...
  • Page 2: Table Of Contents

    DAMAGE. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE REFERENCE. PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED ATTACHMENTS...
  • Page 3: Parts List

    This wall mount is shipped with all proper installation hardware and components. Make sure that none of these parts are missing and/or damaged before beginning installation. If there are parts missing and/or damaged, please stop the installation and contact Premier Mounts (800) 368-9700. Wall Plates...
  • Page 4 Hardware Pack Universal Spacers (Qty 24) Installation Manual M4 x 30 ( Qty 6) M4 x 25 ( Qty 6) M4 x 16 ( Qty 6) M6 x 45 ( Qty 6) M6 x 30 ( Qty 6) M6 x 25 ( Qty 6) M6 x 16 ( Qty 6) PCM-MS2 M5 x 30 ( Qty 6)
  • Page 5: Thread Depth Indicator

    Thread Depth Indicator Step 1. Insert the thread depth indicator (supplied) through the thread inserts found on the back of the flat panel to make sure the inserts measure the same full depth and mark it. Step 2. Locate the correct diameter screw for the thread insert. Compare your marking to the screws (supplied). Step 3.
  • Page 6: Finding The Center Of The Flat Panel Display

    PCM-MS2 Finding the Center of the Flat Panel Display Proper installation procedure by qualified personnel as outlined in the installation instructions must be adhered to. Failure to do so could result in personal injury and possible damage to the flat panel. Invert the flat panel and place it on a soft, flat surface to prevent damage to the flat panel.
  • Page 7: Griplate™ Installation

    Step 3. Match the center of viewing guide with the center line you marked in step 1. Griplate™ Installation Dimples Phillips Head Screwdriver DIMPLES FACING UP Step 1. Pre-install two (2) M6 x 30 (mm) Phillip pan screws to the bottom of the left and right mounting brackets.
  • Page 8: Wall Plate End Covers Installation

    PCM-MS2 Wall Plate End Covers Installation Step 1. Place the upper and lower wall plates on a flat surface. Step 2. Align the wall plate end cover with the wall plate center rods (see illustration above). Wall Stud Location 16" Step 1.
  • Page 9 PCM-MS2 16" Step 5. Level the wall plate with the reference arrow pointing up to the ceiling. Step 6. Drill eight (8) ¼" pilot holes to the marked wall. Completed Installation Diagram Page 9 Step 7. Secure the upper and lower wall plates using the eight (8) 5/16"...
  • Page 10: Securing The Flat Panel To The Wall Mount

    PCM-MS2 Securing the Flat Panel to the Wall Mount AT LEAST (2) PEOPLE ARE STRONGLY RECOMMENDED TO LIFT AND SECURE THE FLAT PANEL TO THE WALL PLATE. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY AND POSSIBLE DAMAGE TO THE FLAT PANEL.
  • Page 11: Lateral Shift Adjustment

    PCM-MS2 Lateral Shift Adjustment Step 1. Make any lateral shift adjustment and lock it by tightening the two (2) M6 x 30mm (supplied) to the bottom of the mounting brackets. Installing the Safety Knurl Knobs Step 1. Tilt the flat panel and secure the two (2) M6 x 12 mm) safety knobs to each of the mounting brackets.
  • Page 12: Technical Specifications

    PCM-MS2 Technical Specifications All measurements are in inches(mm). Installation Manual Page 12...
  • Page 13: Warranty

    What Premier Mounts Will Do At the sole option of Premier Mounts, Premier Mounts will repair or replace any product or product part that is defective. If Premier Mounts chooses to replace a defective product or part, a replacement product or part will be shipped to you at no charge, but you must pay any labor costs.
