Introduction
Congratulations on y our purchase of t his Extech BR200 (17mm c amera head) or B R250 (9mm
camera head) Video B orescope. This instrument was des igned for us e as a remote i nspection
device. It can be used to peer into tight spots and then supply real-time video and i mages t hat can
be r ecorded. Typical applications include HVAC i nspection, aut omotive inspection, cable routing,
and automotive/boat/aircraft inspection. This meter is shipped fully tested and, with proper use, will
provide years of reliable s ervice.
Features
• 3.5 '' TFT-LCD palm L CD monitor with high resolution
• The image head and t he cable are water resistant when the unit is fully assembled (the
monitor and the camera are not water r esistant)
Wireless and hard-wired functionality
•
• The monitor records video and images
• Micro SD card memory (16G max. size).
Safety
• Do not expose i nstrument t o moisture
• Shut off the instrument when not in use
• Remove the bat teries when cleaning t he i nstrument
• Replace all batteries at the same time

Supplied Equipment

1. Camera
2. LCD M onitor
3. Monitor A daptor
4. Adaptor c able
5. Accessory Magnet / Hook / Mirror
6. Magnetic m ount
7. Flex cable and camera head
8. 4 AA Batteries
Note: Micro SD card and adaptor (not shown)
