Introduction
Congratulations on your purchase of this Extech BR200 (17mm camera head) or BR250 (9mm
camera head) Video Borescope. This instrument was designed for use as a remote inspection
device. It can be used to peer into tight spots and then supply real-time video and images that can
be recorded. Typical applications include HVAC inspection, automotive inspection, cable routing,
and automotive/boat/aircraft inspection. This meter is shipped fully tested and, with proper use, will
provide years of reliable service.
Features
3.5 '' TFT-LCD palm LCD monitor with high resolution
The image head and the cable are water resistant when the unit is fully assembled (the
monitor and the camera are not water resistant)
Wireless and hard-wired functionality
The monitor records video and images
Micro SD card memory (16G max. size); Please use Class 4 (or higher) TF Flash memory card
Safety
Do not expose instrument to moisture
Shut off the instrument when not in use
Remove the batteries when cleaning the instrument
Replace all batteries at the same time

Supplied Equipment

1.
Camera
2.
LCD Monitor
3.
Monitor Adaptor
4.
Adaptor cable
5.
Accessory Magnet / Hook / Mirror
6.
Magnetic mount
7.
Flex cable and camera head
8.
4 AA Batteries
Note: Micro SD card and adaptor (not shown)
2
BR200-BR250-en-GB_v7.5 4/17
