Installing the accessory tools （BR200）
The included ac cessories (mirror, hook and magnet) all attach to the camera in the same manner.
Refer to the diagrams below:
Installing the accessory tools （BR250）
Hook the attachment into the hole in the head and then slide the rubber sleeve over the
attachment s haft
Attaching the Monitor to the instrument body
Connect the USB Cable
Use the USB cable to connect the monitor to a PC. The USB onl ine i con will appear on t he
PC. Open My Computer on the PC, and locate the Mobile Disk. The Mobile disk can be
used and ac cessed in the same manner as any external hard drive.
Video Output
Insert the video cable into the VIDEO OUT socket on the monitor. Insert t he other end of t he
cable i nto the VIDEO IN jack of a TV or other m onitor. The LCD Monitor will output a high
quality video image.
Installing the Magnetic bracket
The magnetic bracket s lides onto the r ear of t he monitor for c onvenient placement and
viewing.
