Managing Data
Connecting to a Wireless Network
The following table shows the possibilities:
Entirely grey
(in the list of networks)
Partially or entirely green
Not visible (in the title bar)
By default, your unit supports unsecured networks and networks secured
with the WPA2-PSK protocol. This means that you do not have any special
configuration to make on your unit before connecting to such networks.
Note: It is also possible to configure other types of protocols to match the type of
network that you may have (Advanced configuration tool).
The networks are identified either as "Unsecured" (no protocol) or
"Secured" with the protocol that is used. Dimmed rows indicate networks
that use a protocol requiring a manual configuration. In this case, you may
need to contact your network administrator about the configuration details.
98
Icon
The wireless network is out of range.
The wireless network is in range of your
unit. The number of displayed waves in
green reflects the quality of the signal.





Meaning
Unit is not equipped with Wi-Fi and
®
Bluetooth option.
Wi-Fi and Bluetooth
supported on this model.
Wi-Fi and Bluetooth
disabled (see Enabling or Disabling
the Wi-Fi and Bluetooth® Module on
page 103).
The wireless network to which the
unit was connected is now out of
range.
The unit is not connected to any
wireless network.
®
are not
®
module is
