Installing the Mobile Holder / Antenna
The black antenna on the top of the Transmitter can be swapped with the
mobile phone holder, if you are wanting to view footage live on your phone.
To swap them over, the part fitted can be removed by carefully pulling it
directly upwards, while rocking slightly to unclip it internally. The alternative
piece can then be pushed into position.
Propeller Installation
A1
B2
Front
with the black nuts. Use the small supplied rod threaded through the
nut to ensure the nuts are tight, to prevent the propellers becoming
loose during flight.
It is important the correct blades are
B2
placed on the correct motor or the
aircraft will not fly correctly. Each blade is
marked with an A1 or B2 on its underside
to indicate which motor it corresponds to.
A1
They should be placed onto the motor
shaft with the mark on their underside.
B2 propellers should be locked into place
with the silver nuts and the A1 propellers
7 of 18
