Battery Installation
Ensure the drone is turned off using
the power switch on its underside.
Slide the battery into the battery
housing
Battery Charging
Remove the battery from the drone, following the reverse of steps 2 – 4 above.
Plug the charging cable from the
battery into the socket on the
charger
The battery will take around 3 hours to fully charge, and will give around 18 –
20 minutes of charge. While charging the led on the charger will be red, and
when fully charged the light will turn green.
Open the battery cover on the rear
of the drone
Connect the power lead from the
battery to the power connector
within the battery housing.
Plug the supplied power supply into
the charger, and plug into a wall
socket to charge.
5 of 18
