- Page 1 USER MANUAL REMOTE CONTROL DRONE WITH HD CAMERA PFBD301 Thank you for choosing ProFlight. Please read this user manual before using this drone and keep it safe for future reference.
-
Page 2: Table Of Contents
CONTENTS SAFETY PREPARING FOR FIRST FLIGHT BATTERY INFORMATION CONTROLLER DIAGRAM MOBILE PHONE HOLDER DRONE DIAGRAM FITTING THE BLADE GUIDES FOLDING THE ARMS PROPELLER REPLACEMENT PREPARING FOR FLIGHT HOW TO CONTROL YOUR DRONE MAIN FUNCTIONS WI-FI AND PHONE CONNECTION CONTROLLING THE DRONE USING THE APP TROUBLESHOOTING SUPPORT SPECIFICATION... -
Page 3: Safety
SAFETY WARNINGS • Read the entire instruction manual and familiarise yourself with the product and all its features before operating. • Failure to operate the product correctly can result in damage to the product, surroundings or even serious injury. • This product is not a toy and must be operated with caution and common sense. It requires some basic mechanical knowledge. - Page 4 SAFETY PRECAUTIONS Only fly in an Ensure good Keep within Fly at a height open space GPS signal line of sight below 80m • When flying ensure that the drone is kept away from other people, trees, electric wires, buildings, airports or signal transmitting tower etc.
-
Page 5: Preparing For First Flight
PREPARING FOR FIRST FLIGHT 1. Fully read and understand the safety warnings, and precautions. 2. Make sure both the transmitter and aircraft batteries are sufficiently charged. 3. Find a suitable place to fly the aircraft, away from people, buildings and vehicles. 4. -
Page 6: Controller Diagram
INSTALLING THE CONTROLLER BATTERIES Unclip the battery covers from the rear of the controller and insert 4 x AAA batteries, making sure the correct polarity is followed. Once the batteries are correctly installed, the battery cover must be re-fitted. (Batteries not supplied) CONTROLLER DIAGRAM One Button Landing... -
Page 7: Mobile Phone Holder
MOBILE PHONE HOLDER Hook the phone holder onto the controller by sliding the main hook through the centre hole and clipping the back lock into place. DRONE DIAGRAM FITTING THE BLADE GUARDS Press the blade guards into position. -
Page 8: Folding The Arms
FOLDING THE ARMS Fold the front arms backwards until they sit close to the body of the drone. Fold the rear arm down until it is parallel to the body. DO NOT FORCE THE ARMS AWAY FROM THE BODY AS THIS MAY RESULT IN DAMAGE. -
Page 9: Preparing For Flight
PREPARING FOR FLIGHT Power on the remote control by pressing and holding the power button in the middle of the controller. Turn on the drone by pressing the button shown. Place the drone gently onto the ground. Push the throttle lever and the direction lever in the direction of the arrows shown. -
Page 10: How To Control Your Drone
HOW TO CONTROL YOUR DRONE Ascending and Descending Push the throttle lever up and the drone will gain height. Push the throttle lever down and the drone will descend. Moving Forward and Backwards Push the direction lever up to move the drone forward and down to move the drone backwards. - Page 11 Left and Right Turn Push the throttle to the left or right and the drone will turn in the corresponding direction. Left and Right Flying Push the direction lever left or right and the drone will fly in the corresponding direction. TRIMMING To recover the drone back to the original factory settings for trim.
-
Page 12: Main Functions
MAIN FUNCTIONS Headless Flight The drone can be made to fly in Headless mode by pressing the headless flight button. This will make the aircraft fly without a front or rear. It will fly in the orientation of the pilot. It does not matter which direction the drone is facing in headless mode. -
Page 13: Wi-Fi And Phone Connection
Wi-Fi AND PHONE CONNECTION Install the YX Wi-Fi app on your device by scanning the relevant QR code below. ANDROID After you have installed the app open the app and you will be greeted with the homepage. Ensure the drone is turned on and enter WI-FI SETTINGS by pressing the WIFI settings on the top left of the homepage. - Page 14 After successfully connecting the drone return to the homepage and press the SETTING button. In the settings menu you can chose your control mode to suit your preferred layout. Within the settings menu you can also update the firmware and alter the camera settings, video settings and language.
-
Page 15: Controlling The Drone Using The App
CONTROLLING THE DRONE VIA THE APP Once you have adjusted the settings to your liking you will be able to control the drone through the control screen on your phone, this can be accessed by pressing the start button on the homepage. For ease of use we recommend you mount your phone in the provided phone holder. - Page 16 TAKE PHOTO Press once to take a picture. Press once to start video TAKE VIDEO capture. Press again to cancel and save video. Press once to turn on the on- screen joysticks. Press again TURN THE ON SCREEN to turn them off. The on- JOYSTICKS ON screen joystciks work in the same way as the controller...
-
Page 17: Troubleshooting
WARNING: • Always calibrate the drone before controlling using the APP. • Ensure you understand the operating instructions provided before attempting to fly. • Android device operating system must be 5.0 or higher. • If you experience problems with the image, the drone is either too far away or there is too much interference in the area. -
Page 18: Support
SUPPORT Disposal: Do not dispose this product as unsorted municipal waste. Collection of such waste must be handled separately as special treatment is necessary Recycling facilities are now available for all customers at which you can deposit your old electrical products. Customers will be able to take any old electrical equipment to participating civic amenity sites run by their local councils.
