This section reference information for the SW HDMI Series switchers. Topics that are
covered include:
•
•
•

Specifications

Video
Maximum data rate ........................ 6.75 Gbps (2.25 Gbps per color)
Maximum pixel clock ...................... 165 MHz
Resolution ...................................... Up to 1080p @ 60 Hz or 720p/1080i @ 120 Hz, 12-bit color
Formats .......................................... RGB and YCbCr digital video
Standards ....................................... DVI 1.0, HDMI, HDCP 1.4
NOTE: The SW HDMI Series switchers support TMDS data rates up to 6.75 Gbps, Deep Color up to 12-bit, 3D,
HD lossless audio, and other HDMI specification features.
Video input
Number/signal type ........................ 2 or 4 (depending on model) single link HDMI (or DVI-D*)
Connectors .................................... 2 or 4 female HDMI type A
Video output
Number/signal type ........................ 1 single link HDMI (or DVI-D*)
Connectors .................................... 1 female HDMI type A
Control/remote — switcher
Serial control port ........................... (1) RS-232, 3.5 mm captive screw connector, 5 pole (shared with autoswitching
Baud rate and protocol ................... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations ..... 1 = Tx, 2 = Rx, 3 = GND
Contact closure .............................. (1) 3.5 mm captive screw connector, 5 pole (shared with RS-232)
Contact closure pin configurations . Pins 4 and 5 shorted together turn autoswitch mode on.
IR controller module ....................... IR 102 remote control (optional)
Program control ............................. Extron Simple Instruction Set (SIS
General
Power supply .................................. External
Specifications
Part Numbers
Mounting the SW HDMI
control)
30' maximum, 40 degrees off axis
Input: 100-240 VAC, 50-60 Hz
Output: 12 VDC, 1 A, 12 watts
)
™
SW HDMI Series • Reference Information 28
