Ribbon Options

Home Ribbon Options

File
Open: Open another file. This will create another tab for that processed file. Click on the tab for the file
you want displayed. That will be the current tab.
Save: Save the file located in the current tab.
Close: Close the file located in the current tab.
Processing Options
Focus
When the software automatically processes your data, it will use the dielectric number you
configured and used when the data were collected. This value may or may not give you the
optimum 3D display. The objects displayed in the 3D view may look blurred or blobby.
You can use the Focus option to re-adjust the dielectric for better depth accuracy and a better 3D display.
1
Close the 3D Tab by clicking on the X of the tab so only the original file tab remains.
MN 70-813 Rev E 38
