First Time Setup
Note: The Mini XT incorporates a touch screen. You can use the handle keypad or touchscreen to access
most of the menu items.
Setting UI App Mode
The StructureScan Mini XT apps are divided into two categories for ease of use. These categories are
referred to as UI Modes. The UI Modes are accessible from the menu carousel, secondary menu:
• Simple Mode: ScanEZ
• Standard Mode: ScanEZ, ScanMax, Scan3D
• Advanced Mode: ScanEZ, ScanMax, Scan3D, DualScan
For first time setup, make sure that the Mini XT is in Standard UI mode.
1
Set Language: Make sure that the Mini XT is in ScanMax App. Click the Down arrow to highlight
the menu carousel and then the Left/Right arrows to choose Select Language. Click the middle
keypad button or press the softkey on the carousel to select. Choose your desired language. This may
cause the Mini XT to restart.
2
Set Units: In the ScanMax App, choose Units from the menu carousel. Click the middle handle
keypad button to press the softkey to toggle between English (Imperial) and Metric units.
3
Calibrate Antenna: In the ScanMax App, select Calibrate Antenna from the menu carousel. Follow
the onscreen instructions. Calibrating will set appropriate gain levels.
4
Set Date/Time: In the ScanMax App, choose the secondary menu softkey: Click the middle
handle button or push the softkey to toggle to the ScanMax secondary menu carousel.
Follow the onscreen instructions to set the appropriate date and time.
The choices you have made here will carry over to the ScanEZ and the Scan3D Collection Apps.
MN 70-813 Rev E 4
StructureScan™ Mini XT
Manual
Secondary Menu
