Setup and Connection
Wired (USB) connection with the radio
For the wired connection between the radio and Swift A200, use the USB cable
supplied with Swift A200.
Note: Before connecting Swift A200 to a MOTOTRBO two-way radio with the USB
cable, power off the radio and make sure that Swift A200 is disconnected from
the power supply.
Connect the cable to the USB connector on the rear panel of Swift A200 and to the
rear accessory connector of the radio.
Note: Once you have reconfigured the radio and/or option board, disconnect the
programming cable from the radio and reboot by powering off and on both
the Swift A200 and the radio.
Figure 10: The radio cable
