To save the configuration on your Swift A200, click the Write button or open
the Device menu and click Write.
3.1.2 Installing the Option Board
The delivery kit includes an option board that you need to install into a MOTOTRBO
radio.
To install the option board into the radio:
Insert the dismantling tool in the groove between the control head and the
radio assembly.
Press the dismantling tool under the control head to release the snap features.
Pull the control head away from the radio assembly. Remove the control head
seal.
Orient the flex cable (supplied in the delivery kit) so that it contacts face the
option board. Secure the connector latch to the flex cable.
Connect the flex cable from the option board to the main board connector.
12
Figure 6: Removing the control head
Figure 7: Connecting the flex cable to the option board
