Setup and Connection
3.1.1 Configuring Swift A200
To configure Swift A200:
Launch TRBOnet Swift CPS. In the main window, select USB as an interface for
device programming at the bottom (Figure 1). Connect the programming cable
to the micro-USB port of Swift A200 and to a USB port of your computer.
If you prefer to program your Swift A200 using the LAN connection, select LAN
as the programming interface and connect Swift A200 to the LAN and to the
power supply.
(Recommended) Update firmware of your Swift A200:
a. Click Options on the Tools menu. In the right pane, make sure that the
Enable changing device mode option is switched on (Figure 2).
b. On the Device menu, click Update Firmware. If you use the LAN
connection for programming, specify the IP address of your Swift A200 and
click Connect.
c. In the Firmware update window, select your Swift A200. Open the Mode
menu and click the preferred mode - "NRF RoIP Gateway" (for the wireless
connection to the radio) or "USB RoIP Gateway" (for the USB connection to
the radio).
d. On the Update to menu, select the latest firmware version. Click Update.
Figure 1: Selecting the USB connection for programming
Figure 2: The device mode change is enabled
