On the other hand, if the device is created, changing the network routing to the AS Routing profile is quite easy. First, select a
device from the list and hit on "Edit" button. Then click on Network section in the left menu.
Figure : Steps to follow when the device is created
In the "Network/cloud routing" section, the new AS Routing profile created must be selected clicking on "Change" button and
then selecting the profile created from the dropdown box displayed in the new pop-up window. Finally, click on "Save" button.
Figure : Select the AS Routing created

14.2. Server configuration

In the customer server installed, users have to configure some parameters in order to be able to communicate to the node and
run the whole system.
The services.ini file, located in data folder, has to be updated with the following information in the actility section.
[actility]
log_level = "ALL"
log_file = "../../logs/actility.log"
server_url = "http://lrc99.thingpark.com:8807/sensor/"
log_level: This level is the minimum level to save logs in the system. Users can select one among these levels:
-
OFF: This option deactivate the log.
-
ERROR : It only reports ERROR messages.
-
INFO: It reports ERROR + INFO messages.
-
DEBUG: it reports ERROR + INFO + DEBUG messages.
-
ALL: It reports everything happened in the process.
log_file: The relative path where the log messages will be saved.
server_url: The downlink URL that Actility gives to send information from the server to the node. This URL will be the
address of the primary Actility LRC cluster.
-45-
Actility
v7.0
