Libelium Waspmote Plug & Sense! Smart Parking Technical Manual page 36

A new form that must be completed will be displayed as you see in the next image.
Figure : Callback form
"Url pattern" field should be filled with the URL to the back-end web server application deployed in your server following steps
described in section 3, that provides access to the Sigfox service.Some extra variables has been added following the information
displayed in the form, in order to send to the service as much information as possible.
http://my_server.com/services/sigfox/?id={device}&time={time}&duplicate={duplicate}&snr=
{snr}&station={station}&data={data}&avgSnr={avgSnr}&lat={lat}&lng={lng}&rssi={rssi}&seq-
Number={seqNumber}&ack=true
The list of all callbacks available will be shown after the callback form is saved. In this list it is mandatory to enable this entry with
a downlink for the service in your server receive information. Perform following 2 actions to enable SigFox downlink:
1. Activate "Downlink" column. There is a bullet in this column, and it must be activated. To activate, just click on it and leave the
bullet coloured.
• Downlink active
• Downlink inactive
2. "Enable" the callback. In the "Enable" column of the callback created, there is a check icon and you have to ensure that it is
checked with a green colour.
• Callback enabled
• Callback disabled
Figure : Callback list
-36-
Sigfox
v7.0
