7.5.2. Start frame number 2

Byte
0
1
2
3
4
5 NM_SLEEP_TIME
6 NM_KEEP_ALIVE
7
8
9
10
11
Figure : Start frame number 2 structure
Name
Basic data
Frame counter
CODE_ID
NM_START
NM_PERIOD
RADIO_MODE
SLEEP_TIME
KEEP_ALIVE
THRESHOLD
Reserved
Detailed description in section "Frame"
Detailed description in section "Frame"
Firmware version
Beginning hour of the night mode
Duration in hours of the night mode
Sleep time between consecutive sensor measurements (during night
mode)
Elapsed time since last transmission to trigger a Keep-Alive frame
(during night mode)
Selected transmission mode between Sigfox, LoRaWAN y their
combinations
Sleep time between consecutive sensor measurements
Elapsed time since last transmission to trigger a Keep-Alive frame
Threshold for detecting a vehicle over the parking slot
Reserved byte. Do not consider.
