TIME SETTINGS
Sleep time: Sleep time between consecutive sensor measurements.
•
Keep-Alive: Elapsed time since last transmission to send a Keep-Alive frame.
•
NIGHT MODE
Enabled: Button to activate/deactivate this option. If it is not active, the following fields will not be effective.
•
Duration: Night mode duration time.
•
• Start hour: Night Mode start hour.
Sleep time: Sleep time between consecutive sensor measurements (during night mode).
•
• Keep-Alive: Elapsed time since last transmission to send a Keep-Alive frame (during night mode).
EXTRA CONFIGURATION
Sensor Threshold: Threshold for detecting a vehicle over the parking slot.
•
• Battery readings per day: Battery readings per day.
Daily frame: Enable/Disable daily frame sending.
•
Reset request: Enable/Disable the reset when a vehicle abandon the parking slot.
•
• Configuration version: Code version identifier.
RADIO MODE
Radio mode: Radio transmission mode among Sigfox, LoRaWAN or their combinations.
•
LoRaWAN join mode: LoRaWAN join mode, ABP or OTAA.
•
Before configuring the platform that we will explain in the following sections, we recommend to configure all the radio nodes
in the web server in order to generate the proper answer to them when a message is received. If, for certain reasons, users can
not configure it, don't worry. All nodes will synchronize date and time with the server but not the remote configuration. To get
the whole functionality, each radio node has assigned an ID that has to be stored internally. Users can create or update the
information of every device.
Figure : Device creation detail
